Komatsu PC200-8 Parts Catalog
PC200-8 S/N 350001-UP
Explore real parts diagrams and catalog sections for this machine.
Available catalogs
PC200-8 S/N 350001-UPThis catalog is selected for PC200-8. Use the machine serial number, if available, to confirm the exact catalog version.
Main catalog sections
Other catalog variants
- PC200-8 S/N 315646-UP
- PC200-8 S/N 310001-315645
- PC200-8 S/N 300001-UP (ecot3)
- PC200-8 S/N C60001-UP
Edition and sample parts
PC200-8 S/N 350001-UP
Publication reference: 0000367c.
Match the complete model and the S/N range above to your machine plate. Also check the section range: it can be narrower than the range on the book cover. This example belongs to the following section, not to every version of the machine.
Damper, (1/2) (#350001-)
| Item | Part number | Source description | Quantity |
|---|---|---|---|
| 1 | 22U-01-21310 | Damper | 1 |
| 2 | 203-01-51120 | Pin | 2 |
| 3 | 01010-81020 | Bolt | 8 |
| 4 | 01643-31032 | Washer | 8 |
| 5 | 6754-11-5440 | Tube | 1 |
| 6 | 07260-20950 | Hose | 1 |
| 7 | 07285-00155 | Clip | 1 |
| 8 | 01010-81050 | Bolt | 8 |
The numbers identify parts in this publication. K-Part provides catalog information; this page does not confirm stock or sell these physical parts.
Open this catalogRecently viewed on this device
Find an exact PDF edition · Explore diagram examples
How to choose the correct Komatsu PC200-8 parts catalog
Match the serial range in the catalog name with the serial number on the machine plate. A book for another range, region or modification may not be the correct version for this PC200-8.
Which catalog should I use?
Start with the listed book and confirm its model and serial range against the machine plate. If the page shows other variants, compare them before opening the complete catalog.
Can I search by part number?
Yes. Open the interactive catalog and enter the part number as printed in the book. The public page does not silently translate or change the number.
What is available on the public page?
The public page can show the verified model, selected book name, serial range, page and diagram counts, available variants and main section links when those facts exist in K-Part.
When is a subscription required?
Public model information is available without signing in. Opening complete working catalog materials and account features may require an active subscription.
