946 035 40
|
Head light assy. |
2 |
|
|
|
|
? |
941 143 40
|
Head light |
6 |
|
|
|
|
? |
946 036 40
|
Retainer |
2 |
|
|
|
|
? |
797 352 73
|
Bulb |
6 |
|
|
|
|
? |
946 033 40
|
Lamp retainer |
2 |
|
|
|
|
? |
946 031 40
|
Lamp retainer |
1 |
|
|
|
|
? |
946 030 40
|
Lamp retainer |
1 |
|
|
|
|
? |
943 696 40
|
Wire cover, right hand |
1 |
|
|
|
|
? |
943 697 40
|
Wire cover, left hand |
1 |
|
|
|
|
? |
507 037 98
|
Nut |
74 |
|
|
|
|
? |
340 465 99
|
Washer |
64 |
|
|
|
|
? |
307 780 99
|
Bolt |
8 |
|
|
|
|
? |
340 467 99
|
Washer |
7 |
|
|
|
|
? |
307 775 99
|
Bolt |
3 |
|
|
|
|
? |
517 122 98
|
Lock washer |
3 |
|
|
|
|
? |
307 752 99
|
Bolt |
8 |
|
|
|
|
? |
517 121 98
|
Lock washer |
12 |
|
|
|
|
? |
307 754 99
|
Bolt |
4 |
|
|
|
|
? |
948 803 40
|
Harness Lightning GG |
1 |
|
|
|
|
? |
343 610 99
|
Washer |
11 |
|
|
|
|
? |
907 854 40
|
Thread pin |
11 |
|
|
|
|
? |
0443451610
|
Clip NW 16 |
27 |
|
|
|
|
? |
0819320010
|
Clip |
2 |
|
|
|
|
? |
955 478 40
|
Harness roof frame - engine housing |
1 |
|
|
|
|
? |
0443452711
|
Clip NW 27 |
10 |
|
|
|
|
? |
0443452110
|
Clip NW 21,5 |
27 |
|
|
|
|
? |
926 550 40
|
Spotlight assy. consist of fig nos. 28-31 |
7 |
|
|
|
|
? |
634 009 40
|
Spotlight |
7 |
|
|
|
|
? |
507 383 99
|
Halogen lamp |
7 |
|
|
|
|
? |
769 155 73
|
Seal |
7 |
|
|
|
|
? |
769 156 73
|
Pane, white |
7 |
|
|
|
|
? |
319 143 99
|
Screw |
6 |
|
|
|
|
? |
343 108 99
|
Lock washer |
6 |
|
|
|
|
? |
948 806 40
|
Harness Lighting Cab support |
-2 |
|
|
|
|
? |
510 744 98
|
Resilient sleeve |
7 |
|
|
|
|
? |
320 978 99
|
Screw |
2 |
|
|
|
|
? |
340 904 99
|
Washer |
2 |
|
|
|
|
? |
346 508 99
|
Lock washer |
2 |
|
|
|
|
? |
510 741 98
|
Resilient sleeve |
30 |
|
|
|
|
? |
307 775 99
|
Bolt |
3 |
|
|
|
|
? |
343 610 99
|
Lock washer |
3 |
|
|
|
|
? |
321 010 99
|
Screw |
16 |
|
|
|
|
? |
933 385 40
|
Plug with bushings assy 2 pol. |
1 |
|
|
|
|
? |
941 777 40
|
Name plate |
22 |
|
|
|
|
? |
056 292 40
|
Cable strap |
22 |
|
|
|
|
? |
907 480 40
|
Cable union DN 10-90 |
5 |
|
|
|
|
? |
440 109 40
|
Sleeve |
7 |
|
|
|
|
? |
907 692 40
|
Fitting M16/DN12 |
3 |
|
|
|
|
? |
655 630 40
|
T-Distributor DN DN 29/23 |
2 |
|
|
|
|
? |
651 461 40
|
Housing assy. |
2 |
|
|
|
|
? |
655 634 40
|
Pipe adapter DN 23/17 |
1 |
|
|
|
|
? |
655 810 40
|
Pipe adapter DN 29/12 |
1 |
|
|
|
|
? |
655 629 40
|
T-Distributor DN 17 |
7 |
|
|
|
|
? |
655 633 40
|
Pipe adapter DN 17/12 |
3 |
|
|
|
|
? |
944 780 40
|
Emergency switch-off assy. |
2 |
|
|
|
|
? |
940 729 40
|
Emergancy switch off |
1 |
|
|
|
|
? |
655 627 40
|
Distributor DN 23/17 |
2 |
|
|
|
|
? |
655 625 40
|
Distributor DN 12/10 |
1 |
|
|
|
|
? |
944 781 40
|
Switch assy. |
1 |
|
|
|
|
? |
940 726 40
|
Light switch |
1 |
|
|
|
|
? |
907 704 40
|
Cable union |
1 |
|
|
|
|
? |
896 521 40
|
End pin |
1 |
|
|
|
|
? |
515 213 40
|
Cable 1,0 |
-2 |
|
|
|
|
? |
515 214 40
|
Cable 2,5 |
-2 |
|
|
|
|
? |
655 649 40
|
Cable protection hose DN 10 |
-2 |
|
|
|
|
? |
655 650 40
|
Cable protection hose DN 12 |
-2 |
|
|
|
|
? |
655 651 40
|
Cable protection hose DN 17 |
-2 |
|
|
|
|
? |
655 652 40
|
Cable protection hose DN 23 |
-2 |
|
|
|
|
? |
655 632 40
|
Pipe adapter DN 17/10 DN 17/10 |
5 |
|
|
|
|
? |
907 623 40
|
Cable union DN 12 |
3 |
|
|
|
|
? |
907 478 40
|
Cable union DN 17 |
2 |
|
|
|
|
? |
517 327 98
|
Reducing |
1 |
|
|
|
|
? |
944 782 40
|
Safety switch assy. |
1 |
|
|
|
|
? |
940 728 40
|
Service switch |
1 |
|
|
|
|
? |
940 869 40
|
Socket |
1 |
|
|
|
|
? |
907 975 40
|
Fitting DN17 |
1 |
|
|
|
|
? |
0819111206
|
Plug |
2 |
|
|
|
|
? |
0819105340
|
Pin |
8 |
|
|
|
|
? |
0819181206
|
Plug assy. |
1 |
|
|
|
|
? |
0819105320
|
Pin |
19 |
|
|
|
|
? |
940 852 40
|
Plug |
14 |
|
|
|
|
? |
907 979 40
|
Fitting PG35/DN 17 |
1 |
|
|
|
|
? |
517 321 98
|
Cable nut |
6 |
|
|
|
|
? |
940 463 40
|
Insulating tube |
-2 |
|
|
|
|
? |
056 070 40
|
Cable sleeve 1,0-1,5 |
12 |
|
|
|
|
? |
907 640 40
|
Wire end ferrule 2,5 |
4 |
|
|
|
|
? |
907 577 40
|
Distributor |
4 |
|
|
|
|
? |
940 629 40
|
Warmth shrink hose |
-2 |
|
|
|
|
? |
906 420 40
|
T-Distributor DN 12 DN 12 |
1 |
|
|
|
|
? |
907 974 40
|
Fitting PG29/DN 12 |
1 |
|
|
|
|
? |
907 692 40
|
Fitting M16/DN 12 |
3 |
|
|
|
|
? |
907 703 40
|
Cable union |
5 |
|
|
|
|
? |
0819212920
|
Plug assy. |
4 |
|
|
|
|
? |
896 520 40
|
End pin |
4 |
|
|
|
|
? |
940 461 40
|
Insulating tube |
-2 |
|
|
