PC3000-6E S/N 06262

Komatsu parts book diagram for PC3000-6E S/N 06262: SLEW RING

00 01 02 03 04 05 06 07 08 09 10 11 12 13 14

	#	Part Number	Partname	Quantity	Options	Reference
	00	898 104 40	Slew ring assy.	1	InternBDB: Hoesch Rothe Erde 191.45.2794.000.41.1502
	01	768 613 73	Nip ring	1	InternKon: 898 104 40 / 10
	02	768 614 73	Ring	1	InternKon: 898 104 40 / 20
	03	768 615 73	Retaining ring	1	InternKon: 898 104 40 / 30
	04	768 616 73	Roller set	1	InternBDB: 168 Stьck 45x44,1 \| InternKon: 898 104 40 / 40
	05	768 617 73	Roller set	1	InternBDB: 228 Stьck 32x31,3 \| InternKon: 898 104 40 / 50
	06	768 618 73	Roller set	1	InternBDB: 223 Stьck 32x31,3 \| InternKon: 898 104 40 / 60
	07	768 619 73	Extension	168	InternBDB: 45 x 44,1 \| InternKon: 898 104 40 / 70
	08	768 620 73	Extension	228	InternBDB: 32 x 31,3 \| InternKon: 898 104 40 / 80
	09	768 621 73	Extension	223	InternBDB: 32 x 31,3 \| InternKon: 898 104 40 / 90
	10	319 323 99	Screw	16	InternBDB: M20 x 90 / 912 \| InternKon: 898 104 40 / 100
	11		lock washer	16	InternBDB: S20 / \| InternKon: 898 104 40 / 110
	12	768 622 73	Lip type seal 9,0m	1	InternBDB: W77 \| InternKon: 898 104 40 / 120
	13	768 623 73	Lip type seal 8,95m	1	InternBDB: W27 \| InternKon: 898 104 40 / 130
	14	989 965	Adhesive	-2	InternBDB: Sicomet 85

Komatsu PC3000-6E S/N 06262 parts catalog PDF

SLEW RING (991-0262) in PC3000-6E S/N 06262. Diagram image and parts list.
