SWITCH BOX 1X1 | PC3000-6 S/N 06280 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-6 S/N 06280

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	932 701 40	Switch cabinet 600X800X210	1
?	907 834 40	Breaker 16 A	2
?	907 827 40	Breaker 16 A	1
?	907 828 40	Breaker 6 A	5
?	940 707 40	Power Breaker	1
?	655 828 40	Heater	2
?	938 383 40	Assembly rail	1
?	906 612 40	Through clamp 2.5	11
?	906 792 40	Protective wire clip 6,0	4
?	906 796 40	Protective wire clamp 95,0 GN/GL	1
?	940 673 40	Clamp	10
?	906 613 40	Cover plate	3
?	906 624 40	Marker	2
?	906 625 40	Marker	2
?	906 626 40	Marker	2
?	906 627 40	Marker	2
?	906 772 40	Cover plate	2
?	906 745 40	Through clamp 35-95	4
?	906 768 40	Through clamp 6,0	23
?	940 878 40	Distribution block	4
?	907 478 40	Cable union DN 17	7
?	941 671 40	Power switch	1
?	940 866 40	Door handle coupling	1
?	906 630 40	Protective wire clip 2,5	1
?	319 416 99	Screw	6
?	324 402 99	Threaded pin	4
?	346 510 99	Lock washer	4
?	332 111 99	Nut	4
?	907 477 40	Cable union DN 12	3
?	907 995 40	Cable union DN 48	1
?	518 311 98	Cable nut	1
?	517 322 98	Cable nut	7
?	517 321 98	Cable nut	3
?	507 025 98	Nut	4
?	318 603 99	Screw	4
?	502 461 98	Screw	2
?	270 905 40	Cable channel	-2
?	517 334 98	Plug	2
?	320 837 99	Screw	13
?	906 775 40	Bridge	11
?	906 628 40	Marker	2
?	906 629 40	Marker	2
?			-2
