Diagram image 1 of 2

PC3000-6 S/N 46165

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 46165

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	627 808 40	Seal fixing fig-nos. 3, 4, 20	2
?	627 824 40	Seal ring	2
?		Upper ring half These parts are not sold separately	2
?		Lower ring half These parts are not sold separately	2
?	890 909 40	Seal fixing fig-nos. 07, 08, 20	4
?	655 733 40	Seal ring	4
?		Upper ring half These parts are not sold separately	2
?		Lower ring half These parts are not sold separately	2
?	905 216 40	Seal fixing fig-nos. 12, 13, 20	2
?	247 090 40	Seal ring	2
?		Upper ring half These parts are not sold separately	2
?		Lower ring half These parts are not sold separately	2
?	900 758 40	Seal fixing fig-nos. 16, 17, 20	2
?	652 174 40	Seal ring	2
?		Upper ring half These parts are not sold separately	2
?		Lower ring half These parts are not sold separately	2
?	509 170 98	Bolt	20
?	269 887 40	Metering valve, assy.	1
?	269 880 40	Metering valve, assy.	1
?	693 442	Body to fig-no: 01	1
?	693 443	Body to fig-no: 02	1
?	693 444	Adjusting screw	1
?	693 445	Nut	1
?	693 446	Screw plug	1
?		Seal These parts are not sold separately	2
?		Disk These parts are not sold separately	2
?		Seal ring These parts are not sold separately	1
?		Bolt with nut These parts are not sold separately	1
?		Disk These parts are not sold separately	2
?		Seal ring These parts are not sold separately	1
?		Piston These parts are not sold separately	1
?		Compression spring These parts are not sold separately	1
?		Spring retainer These parts are not sold separately	1
?		Seal ring These parts are not sold separately	1
?		Disk These parts are not sold separately	1
?		Seal ring These parts are not sold separately	1
?		Disk These parts are not sold separately	1
?		Piston These parts are not sold separately	1
?	693 517	Seal	1
?	693 500	Adapter bolt	1
?	693 501	Valve housing	1
?	693 502	Union	1
?	270 131 40	Metering valve assy.	1
?	697 845 73	Body to fig-no: 26	1
?	551 969 40	Metering valve assy.	1
?	764 009 73	Body to fig-no: 28	1
?	764 312 73	Spare metering valve to fig-nos. 01,02,26,28	1
?	764 780 73	Repair kit	1

Komatsu PC3000-6 S/N 46165 parts catalog PDF

METERING VALVE (991-0091) in PC3000-6 S/N 46165. Diagram image and parts list.
