PRESSURE SEQUENCE STAGE | PC3000-6 S/N 46165 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 2

PC3000-6 S/N 46165

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 46165

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	429 687 40	Top roller, assy.	1
?	429 683 40	Roller bearing	2
?	345 218 99	Dowel pin	2
?	324 067 40	Lifetime seal	2
?	502 869 98	O-ring	2
?	429 685 40	Top roller body with bush	1
?	429 686 40	Top roller body	1
?	429 684 40	Freeze-in bush	2
?	313 484 99	Plug	1
?	429 695 40	Axle	1
?	502 213 98	Bolt	4
?	255 057 40	Washer	4
?	510 516 98	Bolt, cold temperature design	4
?	763 485 73	Seal kit fig-nos: 07,08 and 13	-2
?	906 299 40	Top roller is filled with oil	-2
?	767 997 73	Pressure sequence stage	1
?		Valve seat These parts are not sold separately	1
?		Taper These parts are not sold separately	1
?		Set screw These parts are not sold separately	1
?		Nut These parts are not sold separately	1
?		Nut These parts are not sold separately	1
?		Set screw These parts are not sold separately	1
?		Piston These parts are not sold separately	1
?		Pin These parts are not sold separately	1
?	515 019 98	O-ring	1
?	511 225 98	O-ring	1
?	515 020 98	O-ring	1
?	766 474 73	Washer	1
?	340 627 99	Washer	1
?		Spring These parts are not sold separately	1
?	504 261 98	O-ring	1
?	511 368 98	O-ring	1
?	766 475 73	Seal kit	1
