Diagram image 1 of 2

PC3000-6 S/N 46165

01 02 03 04 05 06 07 08 01 02 03 03 04 04 05

PC3000-6 S/N 46165

01 02 03 04 05 06 07 08 01 02 03 03 04 04 05

#	Part Number	Partname	Quantity	Reference
01	256 164 40	Anticavitation valve assy. NG 20	1
02	501 245 98	O-ring	1
03	367 124 99	O-ring	2
04	690 996	Support ring	2
05		Housing These parts are not sold separately	1
06		Valve cone These parts are not sold separately	1
07	994 889	Compression spring	1
08	994 890	Plug	1
\|$$9	994 841	Seal kit fig-nos: 02-04	1
01		Bleed-off valve, pre-controlled assy. without pressure adjustment	-2
\|$$2	356 197 40	Valve, pre-controlled assy. 150bar	-2
\|$$3	356 198 40	Valve, pre-controlled assy. 350bar	-2
\|$$4	324 559 40	Valve, pre-controlled assy. 125bar	-2
\|$$5	414 238 40	Valve, pre-controlled assy. 180bar	-2
\|$$6	414 239 40	Valve, pre-controlled assy. 190bar	-2
\|$$7	655 571 40	Valve, pre-controlled assy. 310bar	-2
\|$$8	906 711 40	Valve, pre-controlled assy. 280bar	-2
02		Pressure relief valve	1	090-0186
03	368 097 40	Support ring	2
04	000 157 98	O-ring	2
05	994 304	Seal kit to fig-no: 02	1
