LINES FOR FEED PUMP - ENGINE OIL | PC5500-6 S/N 15083

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 2

PC5500-6 S/N 15083

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15083

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	907 321 40	Union	4
?	551 404 40	Socket	2
?	374 409 99	Socket	6
?	654 892 40	Union	6
?	655 294 40	Union	4
?	653 525 40	Hose assy., with fire protection coating, DN 20x840	2
?	518 208 98	Hose assy., with fire protection coating, DN 20x3000	2
?	518 029 98	Hose assy., with fire protection coating, DN 16x450	2
?	307 800 99	Bolt	8
?	343 112 99	Lock washer	8
?	518 028 98	Hose assy., with fire protection coating, DN 16x400	2
?	770 563 73	Pump	1
?	518 209 98	Hose assy., with fire protection coating, DN 20x3850	2
?	518 210 98	Hose assy., with fire protection coating, DN 20x3760	1
?	518 211 98	Hose assy., with fire protection coating, DN 20x4250	1
?	516 160 98	Socket	10
?	517 599 98	Socket	4
?	634 298 40	Union	4
?	768 441 73	Bypass filter (Diesel Engine)	4
?	918 814 40	Oilmanagement System	1
?	944 845 40	Oilmanagement System, without Centinel	1
?	792 330 73	Sludge Collecting Paper	20
?	907 565 40	Fluid level indicator with swimming ball inclusive fig.no. 41 a. 42 450 mm lg.	2
?	972 099	O-ring	4
?	511 602 98	Banjo bolt	4
?	534 020 99	Weld on plate	10
?	511 858 98	Cover plate	10
?	514 327 98	Clamp set	10
?	308 540 99	Bolt	10
