PC3000-6 S/N 46228

Komatsu parts book diagram for PC3000-6 S/N 46228: GEAR GREASING BY PINION

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?		Metering valve	1		991-0091
	?	507 596 98	Washer	2
	?	334 599 99	Nut	2
	?	941 505 40	Lube pinion	1
	?	334 600 99	Nut	4
	?	328 383 99	Bolt	4
	?	340 467 99	Washer	4
	?	930 629 40	Pinion cover	1
	?	307 804 99	Bolt	5
	?	517 118 98	Lock washer	5
	?	374 421 99	Socket	1
	?	551 391 40	Union	1
	?	516 843 98	Union	1
	?	634 481 40	Union	1
	?	360 940 40	Connecting tube	3
	?	576 160 40	Hose	-2
	?	341 754 40	Ultimate pressure control	1
	?	512 273 98	Socket	1
	?	906 981 40	Union	7
	?	515 028 40	Collet	2
	?	515 027 40	Hose connection	1
	?	515 029 40	Hose connection 90°	1
	?	515 885 98	Socket	1
	?	516 741 98	Union	1
	?	654 130 40	Protection cap to fig-no. 01	4
	?	371 271 99	Union nut	8
	?	907 080 40	Olive	8
	?	518 021 98	Socket	1
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2
	?			-2

Komatsu PC3000-6 S/N 46228 parts catalog PDF

GEAR GREASING BY PINION (485-2338c) in PC3000-6 S/N 46228. Diagram image and parts list.
