Diagram image 1 of 4

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 08164

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	901 176 40	Door w/o hinge	1
?	901 191 40	Wall	1
?	901 182 40	Door w/o hinge	1
?	901 178 40	Door	2
?	901 175 40	Wall	1
?	912 790 40	Wall	1
?	914 751 40	Door frame w/o hinge	1
?	902 005 40	Post	1
?	902 007 40	Post	1
?	624 004 40	Post	2
?	902 008 40	Post	1
?	902 010 40	Post	1
?	390 199 40	Hinge assy.	17
?	891 420 40	Catch	1
?	902 011 40	Flat steel	1
?	902 012 40	Flat steel	1
?	902 013 40	Flat steel	1
?	902 014 40	Flat steel	1
?	902 015 40	Flat steel	1
?	908 073 40	Strip	1
?	308 614 99	Bolt	2
?	906 709 40	Fastener w/o lock pin	4
?	318 116 99	Screw	8
?	332 442 99	Nut	8
?	166 575 40	Profiled joint Bulk ware, state length required	-2
?	308 610 99	Bolt	19
?	334 600 99	Nut	25
?	304 369 99	Bolt	32
?	510 725 98	Resilient sleeve	32
?	510 742 98	Resilient sleeve	12
?	308 404 99	Bolt	12
?	931 424 40	Post	1
?	514 085 98	Bolt	14
?	902 019 40	Pipe	2
?	307 806 99	Bolt	4
?	902 020 40	Plate	1
?	902 021 40	Plate	2
?	902 022 40	Angle	1
?	332 334 99	Nut	14
?	908 071 40	Catch	4
?	345 178 99	Dowel pin	4
?	561 904 40	Pipe	1
?	912 701 40	Angle	1
?	621 108 40	Pin	1
?	390 600 40	Round bar steel	2
?	390 601 40	Round bar steel	1
?	340 612 99	Washer	1
?	342 061 99	Cotter pin	1
?	350 562 99	Grease nipple	1
?	894 299 40	Roof section	1
?	901 811 40	Roof section	1
?	901 820 40	Roof section	1
?	901 833 40	Threaded rail	2
?	901 832 40	Threaded rail	2
?	901 834 40	Threaded rail	2
?	901 835 40	Threaded rail	2
?	510 741 98	Resilient sleeve	37
?	500 816 98	Bolt	37
?	307 949 99	Bolt	5
?	504 271 98	Lock washer	5
?	592 259 40	Profiled joint Bulk ware, state length required	-2
?	490 694 40	Moulding material 20x20 Bulk ware, state length required	-2
?	180 894 40	Plug	11
?	304 172 99	Bolt	12
?	255 056 40	Washer	12
?	901 840 40	Roof frame	1
?	324 741 40	Plug	4
?	902 030 40	Deflector	1
?	903 938 40	Deflector	1
?	905 072 40	Door, r.h.	1
?	905 078 40	Door, l.h.	1
?	440 821 40	Moulding material 30x30 Bulk ware, state length required	-2
?	902 034 40	Angle	2
?	642 918 40	Key	2
?	308 612 99	Bolt	10
?	332 334 99	Nut	4
?	511 263 98	Thread pin	20
?	507 037 98	Nut	40
?	340 605 99	Washer	20
?	914 710 40	Pipe	1

Komatsu PC4000-6 S/N 08164 parts catalog PDF

COVERING, ENGINE HOUSING (355-1030c) in PC4000-6 S/N 08164. Diagram image and parts list.
