PC5500-6 S/N 15049

Komatsu parts book diagram for PC5500-6 S/N 15049: SLEW RING ARR. STANDARD / COLD WEATHER

01 02 03 03 03 04 05 06 07 08 1 1 1 1 1 1 1 1 1 1 1 10 11 12 13 13 13 13 13 14 15 19

	#	Part Number	Partname	Quantity	Options	Reference
	01	928 750 40	Slew ring	1	InternBDB: 928 750 40
	02	508 154 98	Bolt	132	InternBDB: M36x500 NT \| InternKon: 933 974 40 / 3
	02	508 155 98	Bolt, Cold weather	132	InternBDB: M36x500 NT \| InternKon: 933 974 40 / 3
	03	255 056 40	Washer	148	InternBDB: Ш 37 \| InternKon: 933 974 40 / 4
	04	368 518 40	Bolt	124	InternBDB: M36x230 NT \| InternKon: 933 972 40 / 2
	04	505 288 98	Bolt, Cold weather	124	InternBDB: M36x230 \| InternKon: 933 972 40 / 2
	05	409 437 40	Test bolt	8	InternBDB: M36x230 \| InternKon: 933 972 40 / 3
	05	409 484 40	Test Bolt, Cold weather	8	InternBDB: M36x230 \| InternKon: 933 972 40 / 3
	06	379 077 40	Tension piece	1	InternBDB: 227 \| InternKon: 379 076 40 / 2
	07	376 792 40	Jaw	1	InternKon: 379 076 40 / 1
	08	324 969 40	Compound (2 LBS) (1,3 kg.)	5	InternBDB: GM 519 8563
	\|$$12	794 840 73	Slew ring - mounting kit fig-nos. 02-08	1	InternBDB: E-ST
	10	933 249 40	Sheet metal	1	InternKon: 933 250 40 / 1
	11	620 850 40	Cover	6	InternKon: 933 250 40 / 5
	12	933 257 40	Protection casing	1	InternKon: 933 250 40 / 4
	13	933 252 40	Sheet metal	5	InternKon: 933 250 40 / 2
	14	510 741 98	Resilient sleeve	29	InternKon: 933 250 40 / 6
	15	308 436 99	Bolt	29	InternBDB: M12x75 /931 \| InternKon: 933 250 40 / 7
	19	933 255 40	Sheet metal	-2	InternKon: 933 250 40 / 3
