01 |
|
Spread beam headlamp |
4 |
|
991-0377 |
|
|
02 |
340 461 99
|
Washer |
32 |
|
|
|
|
03 |
507 036 98
|
Nut |
16 |
|
|
|
|
04 |
504 010 98
|
Bolt |
32 |
|
|
|
|
05 |
910 023 40
|
Plate |
1 |
|
|
|
|
06 |
440 461 40
|
Wall socket 63A |
2 |
|
|
|
|
07 |
440 462 40
|
Plug |
2 |
|
|
|
|
08 |
321 015 99
|
Bolt |
4 |
|
|
|
|
09 |
440 373 40
|
Camswitch |
1 |
|
|
|
|
10 |
621 314 40
|
Safety cut off |
1 |
|
|
|
|
11 |
057 278 40
|
Socket |
2 |
|
|
|
|
12 |
517 328 98
|
Reducing M25/M20 |
6 |
|
|
|
|
13 |
517 327 98
|
Reducing M20/M16 |
7 |
|
|
|
|
14 |
517 326 98
|
Reducing M16/M12 |
8 |
|
|
|
|
15 |
655 649 40
|
Protecting hose DN 10 |
-2 |
|
|
|
|
16 |
898 629 40
|
Rotaflare light yellow assy. |
1 |
|
|
|
|
17 |
898 612 40
|
Retainer |
1 |
|
|
|
|
18 |
896 497 40
|
Rotaflare light 24 yellow |
1 |
|
|
|
|
19 |
515 213 40
|
Cable 1,0 |
-2 |
|
|
|
|
20 |
180 322 40
|
Plug |
1 |
|
|
|
|
21 |
323 960 40
|
Tab |
2 |
|
|
|
|
22 |
904 476 40
|
Cable union DN 10 |
7 |
|
|
|
|
23 |
903 422 40
|
Plug head light assy. |
4 |
|
|
|
|
24 |
907 692 40
|
Fitting DN 16/12 |
4 |
|
|
|
|
25 |
907 704 40
|
Cable union |
5 |
|
|
|
|
26 |
896 521 40
|
End pin |
5 |
|
|
|
|
27 |
515 214 40
|
Cable 2,5 |
-2 |
|
|
|
|
28 |
056 071 40
|
Cable sleeve 2,5 |
50 |
|
|
|
|
29 |
|
Junction box |
1 |
|
715-2180 |
|
|
30 |
919 435 40
|
Retainer |
35 |
|
|
|
|
31 |
056 070 40
|
Cable sleeve 1,0-1,5 |
46 |
|
|
|
|
32 |
515 213 40
|
Cable 1,0 |
-2 |
|
|
|
|
33 |
919 442 40
|
Retainer |
22 |
|
|
|
|
34 |
056 059 40
|
Cable sleeve |
4 |
|
|
|
|
35 |
655 650 40
|
Cable protection hose DN 12 |
-2 |
|
|
|
|
37 |
655 625 40
|
Distributor DN 12/10 |
1 |
|
|
|
|
38 |
655 081 40
|
Cable 2,5 br |
-2 |
|
|
|
|
39 |
655 629 40
|
T-Distributor DN 17 |
2 |
|
|
|
|
40 |
655 632 40
|
Pipe adapter DN 17/10 |
4 |
|
|
|
|
41 |
907 478 40
|
Cable union DN 17 |
3 |
|
|
|
|
42 |
655 651 40
|
Cable protection hose DN 17 |
-2 |
|
|
|
|
44 |
256 514 40
|
Name plate |
20 |
|
|
|
|
45 |
056 292 40
|
Cable strap |
20 |
|
|
|
|
47 |
655 634 40
|
Pipe adapter DN 23/17 |
1 |
|
|
|
|
48 |
655 630 40
|
T-Distributor DN 29/23 |
2 |
|
|
|
|
49 |
906 079 40
|
T-Distributor DN 29 |
2 |
|
|
|
|
50 |
655 631 40
|
Pipe adapter DN 12/10 |
4 |
|
|
|
|
51 |
655 809 40
|
Pipe adapter DN 29/10 |
2 |
|
|
|
|
52 |
517 323 98
|
Nut |
3 |
|
|
|
|
53 |
320 976 99
|
Screw |
12 |
|
|
|
|
54 |
906 413 40
|
Cable channel |
-2 |
|
|
|
|
55 |
319 914 99
|
Screw |
6 |
|
|
|
|
56 |
346 510 99
|
Lock washer |
6 |
|
|
|
|
57 |
321 010 99
|
Screw |
6 |
|
|
|
|
58 |
916 658 40
|
Retainer |
3 |
|
|
|
|
59 |
635 143 40
|
Emergency switch-off |
4 |
|
|
|
|
60 |
923 578 40
|
Harness - lighting equipment outer |
1 |
|
|
|
|
61 |
923 580 40
|
Harness - lighting equipment counterweight |
1 |
|
|
|
|
62 |
319 140 99
|
Bolt |
20 |
|
|
|
|
63 |
145 831 40
|
Clamp 20/15 |
1 |
|
|
|
|
64 |
510 210 98
|
Thread pin |
30 |
|
|
|
|
65 |
507 025 98
|
Nut |
37 |
|
|
|
|
66 |
006 301 98
|
Clamp 12/15 |
17 |
|
|
|
|
67 |
340 628 99
|
Washer |
20 |
|
|
|
|
68 |
350 762 99
|
Washer |
41 |
|
|
|
|
69 |
655 635 40
|
Pipe adapter DN 29/17 |
1 |
|
|
|
|
70 |
655 652 40
|
Protecting hose DN 23 |
-2 |
|
|
|
|
71 |
655 696 40
|
Protecting hose DN 29 |
-2 |
|
|
|
|
72 |
655 084 40
|
Cable 6,0 br |
-2 |
|
|
|
|
73 |
655 085 40
|
Cable 6,0 gr/ge |
-2 |
|
|
|
|
74 |
940 463 40
|
Insulating tube |
-2 |
|
|
|
|
75 |
921 576 40
|
Harness - engine housing |
1 |
|
|
|
|
76 |
551 362 40
|
Camswitch |
2 |
|
|
|
|
77 |
940 271 40
|
Cable union DN 10 |
1 |
|
|
|
|
78 |
324 484 40
|
Cable end sleeve |
8 |
|
|
|
|
79 |
634 135 40
|
Fluorescent lamp |
4 |
|
|
|
|
80 |
634 397 40
|
Fluorescent lamp |
7 |
|
|
|
|
81 |
764 201 73
|
Fluorescent lamp |
7 |
|
|
|
|
82 |
766 904 73
|
Fluorescent lamp |
4 |
|
|
|
|
83 |
334 599 99
|
Nut |
20 |
|
|
|
|
84 |
308 284 99
|
Bolt |
2 |
|
|
|
|
85 |
916 654 40
|
Retainer |
2 |
|
|
|
|
86 |
592 188 40
|
Socket |
2 |
|
|
|
|
87 |
320 976 99
|
Bolt |
12 |
|
|
|
|
89 |
307 727 99
|
Bolt |
6 |
|
|
|
|
90 |
916 648 40
|
Angle |
1 |
|
|
|
|
92 |
655 621 40
|
Cable union DN 10 |
1 |
|
|
|
|
93 |
934 493 40
|
Harness 3X4-4S15 |
1 |
|
|
|
|
94 |
934 493 40
|
Harness 3X4-4S15A |
1 |
|
|
|
|
95 |
934 968 40
|
Press button assy. |
1 |
|
|
|
|
96 |
907 847 40
|
Button |
1 |
|
|
|
|
97 |
907 848 40
|
Contact element |
1 |
|
|
|
|
98 |
940 038 40
|
Button plate |
1 |
|
|
|
|
99 |
655 082 40
|
Cable 2,5 ge/gr |
-2 |
|
|
|
|
100 |
934 495 40
|
Harness socket 3X4-4X2 |
-2 |
|
|
|
|
101 |
933 356 40
|
Harness lighting equipment - 3X4- 7H4 |
1 |
|
|
|
|
102 |
921 563 40
|
Harness lighting equipment - 3X4- 7H3 |
1 |
|
|
|
|
103 |
933 355 40
|
Harness lighting equipment - 3X4- 7H6 |
1 |
|
|
|
|
104 |
933 354 40
|
Harness lighting equipment - 3X4- 7H7 |
1 |
|
|
|
|
105 |
921 564 40
|
Harness lighting equipment - 3X4- 4H41 |
1 |
|
|
|
|
106 |
933 352 40
|
Harness lighting equipment - 3X4- 4H41a |
1 |
|
|
|
|
107 |
933 353 40
|
Harness lighting equipment - 3X4- 4H41b |
1 |
|
|
|
|
108 |
934 490 40
|
Harness lighting equipment - 3X4- 4H43 |
1 |
|
|
|
|
109 |
934 491 40
|
Harness lighting equipment - 3X4- 4H43a |
1 |
|
|
|
|
110 |
934 492 40
|
Harness lighting equipment - 3X4- 4H43b |
1 |
|
|
|
|
111 |
921 549 40
|
Harness 3X4-1X10 |
1 |
|
|
|
|
112 |
921 548 40
|
Harness 3X4 |
1 |
|
|
|
|
113 |
921 550 40
|
Harness 4X3 |
1 |
|
|
|
|
114 |
921 562 40
|
Harness 4X1 |
1 |
|
|
