LUBE STATION ARR. | PC5500-6E S/N 15048 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Reference
01		Lube pump station	2	991-0553b
02	915 680 40	Grease barrel	1
03		Pressure filter	2	090-3139
04	516 322 98	Non-return valve	2
05	308 578 99	Bolt	8
06	510 746 98	Resilient sleeve	8
07	307 757 99	Bolt	8
08	340 464 99	Washer	8
09	374 412 99	Socket	2
10	371 265 99	Union	4
11	906 352 40	Olive	4
12	374 410 99	Socket	2
13	928 707 40	Pipe Ш 30	1
14	928 708 40	Pipe Ш 30	1
15	308 321 99	Bolt	8
16	510 729 98	Resilient sleeve	8
17	332 355 99	Nut	8
18	516 616 98	Socket	2
19	907 051 40	Union	2
20	513 495 98	Hose assy. DN 20x1630	2
21	512 715 98	Hose assy. DN 08x1200	1
22	512 938 98	Hose assy. DN 12x1200	1
23	516 173 98	Socket	1
24	516 175 98	Socket	1
25	515 765 98	Socket	1
26	510 537 98	Socket	1
27	515 862 98	Socket	1
28	516 824 98	Union	1
29	515 570 98	Hose assy. DN 10x2500	1
30	168 491 40	Hose assy. DN 20x2500	1
31	255 400 40	Hose assy. DN 20x1500	1
32	641 482 40	Hose assy. DN 20x2230	1
33	514 130 98	Hose assy. DN 20x13300	1
34	604 071 40	Hose assy. DN 10x 8000	1
35	516 161 98	Socket	1
36	374 431 99	Socket	1
37	551 345 40	Union	1
38	516 618 98	Union	3
39	506 954 98	Nut	3
40	513 144 98	Socket	1
41	509 267 98	Nut	1
42	516 615 98	Union	2
43	509 272 98	Nut	2
44	516 181 99	Socket	2
45	515 224 98	Union	2
46	516 165 98	Socket	2
47	928 709 40	Pipe Ш 20	1
48	928 710 40	Pipe Ш 20	1
49	371 260 99	Union	4
50	906 351 40	Olive	4
51	635 800 40	Fire protection hose	-2
52	932 904 40	Fire protection hose	-2
53	374 921 99	hose clamp	4
54	374 926 99	hose clamp	4
