AIR CONDITION ARR. - CAB SUPPORT AND MS-SWITCH CABINET | PC4000-6E S/N 08202

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options	Reference
01		Compact air condit. equipment see page	2	InternBDB: 796 107 73	991-0763
02	307 754 99	Bolt	24	InternBDB: M8x25 DIN00933
03	343 108 99	Lock washer	24	InternBDB: 8 DIN00128
04	308 582 99	Bolt	6	InternBDB: M10x75 \| InternKon: 945 725 40 / 51
05	334 678 99	Nut	6	InternBDB: M10 \| InternKon: 945 725 40 / 52
06	340 465 99	Lock washer	6	InternBDB: B 10,5 \| InternKon: 945 725 40 / 53
07	932 615 40	Air hose	-2	InternBDB: I-D 152, 2500 mm lang \| InternKon: 945 725 40 / 54
08	007 616 98	Hose clamp	6	InternBDB: S152x25 \| InternKon: 945 725 40 / 55
09	794 979 73	Compressor	2	InternBDB: Sьtrak 2FC-2.2Y 400/50 24VDC 120W
10	940 445 40	Socket	1	InternBDB: Sьtrak 24.09.10.008 7/8
11	940 444 40	Socket	1	InternBDB: Sьtrak 24.09.10.007 1/4
12	941 274 40	Hose DN12	-2	InternBDB: DN12 GH134-10x6500 \| InternKon: 945 753 40 / 12
13	941 272 40	Hose DN16	-2	InternBDB: DN16 GH134-12X6500 \| InternKon: 945 753 40 / 13
14	767 812 73	High pressure switch	2	InternBDB: Sьtrak 26.003.20.251
15	767 813 73	Low pressure switch	2	InternBDB: Sьtrak 26.03.20.002
16	794 141 73	Angle	4	InternBDB: Sьtrak 24.09.05.010 7/16UNF
17	794 144 73	Shock absorber	4	InternBDB: Sьtrak 30.13.02.050
18	533 991 99	Clamp Set	6	InternBDB: L-3-R-20 DIN03015 \| InternKon: 945 753 40 / 3
19	500 980 98	Clamp Set	6	InternBDB: L-3-R-25 DIN03015 \| InternKon: 945 753 40 / 4
20	533 992 99	Weld on plate	12	InternBDB: L-AP-K-3 DIN03015 \| InternKon: 945 753 40 / 5
21	511 856 98	Cover plate	12	InternBDB: L-3 W1 DIN03015 \| InternKon: 945 753 40 / 6
22	308 536 99	Bolt	24	InternBDB: M6x40 8.8 DIN00931 \| InternKon: 945 753 40 / 7
23	343 003 99	Washer	24	InternBDB: 6,4 UST13 03 DIN00093 \| InternKon: 945 753 40 / 8
24	941 275 40	Hose DN12	-2	InternBDB: DN12 GH134-10x11000
25	941 276 40	Hose DN16	-2	InternBDB: DN16 GH134-12x11000
