792 270 73
|
Brake assy. |
1 |
InternBDB: 564767 / zu GFB 174 E 9017 / 9020 / 9021
|
|
|
|
? |
513 532 98
|
Ball bearing |
1 |
InternBDB: 410288 6018 J DIN 625
|
|
|
|
? |
517 016 98
|
Ball bearing |
1 |
InternBDB: 311601 6018 J 2RS / C3 DIN 62
|
|
|
|
? |
509 834 98
|
Socket head cap screw |
8 |
InternBDB: 441277 / M16x50 DIN 912
|
|
|
|
? |
507 748 98
|
O-ring |
1 |
InternBDB: 463378 595x4 DIN 3771
|
|
|
|
? |
313 178 99
|
Screw plug |
1 |
InternBDB: 444210 G1/2" DIN 910
|
|
|
|
? |
339 950 99
|
Seal ring |
1 |
InternBDB: 462057 A 42x49x2 DIN 7603
|
|
|
|
? |
792 242 73
|
Drive Shaft |
1 |
InternBDB: 561677 / 1/0343/9886/0
|
|
|
|
? |
763 841 73
|
Union |
2 |
InternBDB: 309014 EVL 18-PLM
|
|
|
|
? |
319 161 99
|
Socket head cap srew |
2 |
InternBDB: M12x65 / 912
|
|
|
|
? |
313 314 99
|
Plug |
1 |
InternBDB: 444186 / M22x1,5 / 915
|
|
|
|
? |
792 245 73
|
Dipstick G1/2x250 |
1 |
InternBDB: 312387 / G1/2x250
|
|
|
|
? |
340 294 99
|
Seal ring |
1 |
InternBDB: 462045 / A 22x27x1,5 / 7603
|
|
|
|
? |
339 998 99
|
Seal ring |
2 |
InternBDB: 462053 / A 21x26x1,5 / 7603
|
|
|
|
? |
313 367 99
|
Plug |
4 |
InternBDB: 444189 / M30x1,5 / 910
|
|
|
|
? |
339 932 99
|
Seal ring |
4 |
InternBDB: 462055 /A 30x36x2 / 7603
|
|
|
|
? |
376 666 99
|
Radial shaft seal ring |
2 |
InternBDB: 461043 / 100x130x12 A / 3760
|
|
|
|
? |
792 246 73
|
Disk housing |
1 |
InternBDB: 561681 / 0/0579/9401/1
|
|
|
|
? |
792 247 73
|
Piston |
1 |
InternBDB: 561678 / 2/0575/9231/0
|
|
|
|
? |
792 248 73
|
Bearing ring |
1 |
InternBDB: 561680 / 1/0438/9733/1
|
|
|
|
? |
792 249 73
|
Disk |
1 |
InternBDB: 561674 / 4/0401/9517/0
|
|
|
|
? |
792 250 73
|
Inner disk |
10 |
InternBDB: 563058 / 3-002-340-63-155
|
|
|
|
? |
792 251 73
|
Outer disk |
11 |
InternBDB: 312021 / 3-002-210-63-151
|
|
|
|
? |
963 624
|
Pressure spring |
16 |
InternBDB: 423336 / 2,5x11,5x54 DIN 2098
|
|
|
|
? |
342 678 99
|
Snap ring |
1 |
InternBDB: 452285 / 140x4 DIN 472
|
|
|
|
? |
806 036 73
|
Pressure spring |
14 |
InternBDB: 423337 / 1,6x6,5x54 DIN 2098
|
|
|
|
? |
972 122
|
O-ring |
1 |
InternBDB: 463283 / 280x3 / DIN 3771
|
|
|
|
? |
972 122
|
O-ring |
1 |
InternBDB: 463283 / 280x3 / DIN 3771
|
|
|
|
? |
792 252 73
|
Piston seal |
1 |
InternBDB: 563051 / 4378 336Y
|
|
|
|
? |
792 253 73
|
Support ring |
2 |
InternBDB: 563052 / 266x275,4x1,4 P
|
|
|
|
? |
792 254 73
|
Piston seal |
1 |
InternBDB: 563049 / 4379 477 B
|
|
|
|
? |
792 256 73
|
Support ring |
2 |
InternBDB: 563050 / 280,5x290x1,4 P
|
|
|
|
? |
513 135 98
|
Socket head cap srew |
8 |
InternBDB: 445157 / M16x140 DIN 912
|
|
|
|
? |
342 708 99
|
Snap ring |
1 |
InternBDB: 452094 / 295x5 DIN 472
|
|
|
|
? |
792 257 73
|
Locating ring |
1 |
InternBDB: 561675 /
|
|
|
|
? |
972 122
|
O-ring |
1 |
InternBDB: 463283 / 280x3 / DIN 3771
|
|
|
|
? |
342 568 99
|
Snap ring |
1 |
InternBDB: 452062 / 90x3 DIN 471
|
|
|
|
? |
792 258 73
|
Seal ring |
1 |
InternBDB: 561676 /
|
|
|
|
? |
792 259 73
|
Sinus ring |
10 |
InternBDB: 563069 / 1-022-072-63-00000
|
|
|
|
? |
907 602 40
|
O-ring TTT -55 |
1 |
InternBDB: ORAR 00379-N7T40 278,77x5,33
|
|
|
|
? |
907 603 40
|
O-ring TTT -55 |
1 |
InternBDB: ORAR 00378-N7T40 266,07x5,33
|
|
|
|
? |
795 341 73
|
Brake assy., TTT-55°, with O-Ring 555,556 instead of 512,514 |
1 |
InternBDB: TTT-55 564767 / zu GFB 174 E 9021
|
|
|
|
? |
792 271 73
|
Repair Kit Brake consists of fig. nos. 505, 506, 507, 509, 512, 513, 514, 515 |
1 |
InternBDB: 564768
|
|
|
|
? |
795 297 73
|
Repair Kit Brake consists TTT-55 of fig. nos. 505, 506, 507, 509, 513, 515, 555, 556 |
-2 |
|
|
