01 |
|
Heater assembly |
1 |
InternBDB: 797 373 73 | InternKon: 503 009 000 / 1
|
991-0882 |
|
|
02 |
|
Air box |
1 |
InternBDB: Matec 002079015
|
|
|
|
03 |
372 378 40
|
Seal |
1 |
InternKon: 503 009 000 / 2
|
|
|
|
04 |
372 366 99
|
Union |
6 |
InternBDB: YL 18 /2353
|
|
|
|
06 |
255 898 40
|
Hose fittings 90° |
2 |
InternBDB: Aeroquip 07.074-16-10 | InternKon: 503 009 000 / 6
|
|
|
|
07 |
307 422 99
|
Bolt |
4 |
InternBDB: M8x12/933 | InternKon: 503 009 000 / 3
|
|
|
|
08 |
343 108 99
|
Washer |
4 |
InternBDB: 8/127 | InternKon: 503 009 000 / 4
|
|
|
|
09 |
256 626 40
|
Hose DN 16 |
-2 |
InternKon: 503 009 000 / 8
|
|
|
|
10 |
500 078 98
|
Hose clip |
6 |
InternBDB: 1 S 21x15 | InternKon: 503 009 000 / 10
|
|
|
|
11 |
795 954 73
|
Control unit |
1 |
InternBDB: SÑŒtrak 26.09.03.060-02 BT24 | InternKon: 117 500 520 / 2
|
|
|
|
12 |
794 715 73
|
Valve |
1 |
InternBDB: SÑŒtrack 22.05.10.314 2/2-Wege Typ 256 | InternKon: 117 500 520 / 4
|
|
|
|
15 |
516 542 98
|
Hose assy. DN 16x10200 |
1 |
InternBDB: DOL 18-90 /DOS 20 | InternKon: 902 081 40 / 1
|
|
|
|
16 |
516 543 98
|
Hose assy. DN 16x7700 |
1 |
InternBDB: DOL 18-90 /DOS 20 | InternKon: 902 081 40 / 2
|
|
|
|
17 |
516 544 98
|
Hose assy. DN 16x2700 |
2 |
InternBDB: DOL 18 /DOL 18 | InternKon: 902 081 40 / 3
|
|
|
|
18 |
518 472 98
|
Hose assy. DN 16x700 |
2 |
InternBDB: DOL 18 /DOL 18 | InternKon: 902 081 40 / 6
|
|
|
|
21 |
516 165 98
|
Union |
2 |
InternBDB: SWE-S 20 | InternKon: 902 081 40 / 11
|
|
|
|
22 |
374 413 99
|
Socket |
2 |
InternBDB: S 20 E-M /3901 | InternKon: 902 081 40 / 9
|
|
|
|
23 |
509 058 98
|
Half clamp |
10 |
InternBDB: L-3-G-23 /3015 | InternKon: 902 081 40 / 10
|
|
|
|
25 |
511 856 98
|
Cover plate |
10 |
InternBDB: L-3 /3015 | InternKon: 902 081 40 / 12
|
|
|
|
26 |
308 536 99
|
Bolt |
20 |
InternBDB: M 6x40 / 931 | InternKon: 902 081 40 / 13
|
|
|
|
27 |
908 047 40
|
Cover assy. |
1 |
InternKon: 902 185 40 / 6
|
|
|
|
28 |
902 183 40
|
Seal |
1 |
InternKon: 902 185 40 / 9
|
|
|
|
29 |
509 875 98
|
Thread pin |
8 |
InternBDB: PM 8x25 /32500
|
|
|
|
30 |
340 507 99
|
Washer |
8 |
InternBDB: 8,4 /125 | InternKon: 902 185 40 / 17
|
|
|
|
31 |
334 599 99
|
Nut |
8 |
InternBDB: M8 /985 | InternKon: 902 185 40 / 15
|
|
