PRESSURE LINES, TRAVELMOTORS - ROTARY JOINT | PC5500-6 S/N 15056

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 2

PC5500-6 S/N 15056

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC5500-6 S/N 15056

? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options	Reference
?		Brake valve	2	InternKon: 933 611 40 / 7	090-0415a
?	505 263 98	Bolt	4	InternBDB: M20x420 /931 10.9 \| InternKon: 933 611 40 / 8
?	334 686 99	Nut	4	InternBDB: M 20 /985 \| InternKon: 933 611 40 / 9
?	316 212 99	Washer	4	InternBDB: 21 / 6916 \| InternKon: 933 611 40 / 10
?	793 807 73	Pipe assy. Ш 65	2	InternBDB: 905 545 40 \| InternKon: 933 616 40 / 12
?	793 808 73	Pipe assy. Ш 65	2	InternBDB: 905 544 40 \| InternKon: 933 616 40 / 11
?	504 448 98	Flange	8	InternBDB: FE 6500-32/6 \| InternKon: 933 611 40 / 26
?	504 461 98	Collar ring	8	InternBDB: K-6580-32 \| InternKon: 933 611 40 / 27
?	385 243 40	Flange seal	16	InternBDB: 2" NBR 90 \| InternKon: 933 611 40 / 28
?	319 323 99	Bolt	32	InternBDB: M20x90 /912 10.9 \| InternKon: 933 611 40 / 29
?	940 292 40	Hose assy. DN 50x3250	2	InternBDB: FS 2 FS 2 - 90 \| InternKon: 932 336 40 / 5
?	940 442 40	Hose assy. DN 50x3430	2	InternBDB: FS 2 FS 2 - 90 \| InternKon: 932 336 40 / 6
?	319 305 99	Bolt	32	InternBDB: M20x60 /912 10.9 \| InternKon: 932 336 40 / 17
?	932 378 40	Distribution block	4	InternKon: 929 312 40 / 13
?	793 809 73	Pipe assy. Ш 50	4	InternBDB: 932 372 40 \| InternKon: 933 719 40 / 65
?	796 482 73	Pipe assy. Ш 50	4	InternBDB: 946 614 40 \| InternKon: 946 613 40 / 66
?	356 209 40	Quadring	16	InternBDB: 1 1/2 \| InternKon: 929 311 40 / 42
?	500 127 98	Flange	16	InternBDB: FE-5000-24/6 \| InternKon: 932 372 40 / 1
?	501 898 98	Ring	16	InternBDB: K-5060-24 \| InternKon: 932 372 40 / 2
?	319 298 99	Bolt	64	InternBDB: M16 x 55 /912 \| InternKon: 929 311 40 / 43
