01 |
|
Slew gearbox |
2 |
InternBDB: 936 560 40 | InternKon: 925 880 40 / 1
|
991-0715 |
|
|
02 |
|
Slew gear motor |
2 |
InternBDB: 927 032 40 | InternKon: 930 156 40 / 16
|
991-0497 |
|
|
03 |
|
Slew-brake valve |
2 |
InternBDB: 655 855 40 | InternKon: 930 156 40 / 15
|
991-0181a |
|
|
04 |
914 931 40
|
Intermediate plate |
2 |
InternKon: 930 156 40 / 17
|
|
|
|
05 |
356 209 40
|
O-ring |
4 |
InternBDB: 1 1/2 | InternKon: 930 156 40 / 18
|
|
|
|
06 |
319 293 99
|
Bolt |
16 |
InternBDB: M16x100 /912 | InternKon: 930 156 40 / 20
|
|
|
|
07 |
501 784 98
|
Bolt |
8 |
InternBDB: M20x190 /912 | InternKon: 930 156 40 / 19
|
|
|
|
08 |
307 454 99
|
Bolt |
16 |
InternBDB: M16x50 /933 | InternKon: 930 156 40 / 21
|
|
|
|
09 |
316 211 99
|
Washer |
16 |
InternBDB: Ш 17 | InternKon: 930 156 40 / 22
|
|
|
|
10 |
940 006 40
|
Bleeder filter |
4 |
InternBDB: Optional f. Rцssing / 1320-07-00 7 Hunger | InternKon: 925 880 40 / 5
|
|
|
|
12 |
308 639 99
|
Srew |
4 |
InternBDB: M16x110 / DIN 933 / 8.8 | InternKon: 925 880 40 / 8
|
|
|
|
13 |
510 730 98
|
Resilient sleeve |
4 |
InternBDB: 17/30x55 /34194840 | InternKon: 925 880 40 / 7
|
|
|
|
14 |
516 159 98
|
Socket |
4 |
InternBDB: SWE-L18 | InternKon: 925 880 40 / 9
|
|
|
|
15 |
339 907 99
|
Seal ring |
6 |
InternBDB: 22x27x1,5 / CU /7603
|
|
|
|
16 |
515 362 40
|
Oil drain coupling |
2 |
InternBDB: M26x1,5 / Roelex | InternKon: 925 880 40 / 6
|
|
|
|
24 |
517 612 98
|
Srew |
68 |
InternBDB: M 24x550 / 912 / 12.9 | InternKon: 925 880 40 / 2
|
|
|
|
25 |
516 920 98
|
Washer |
68 |
InternBDB: 25,0 / DIN 433 | InternKon: 925 880 40 / 3
|
|
|
|
26 |
907 142 40
|
Plug |
68 |
InternBDB: Z 36x25 GPN 200 | InternKon: 925 880 40 / 4
|
|
|
|
31 |
944 861 40
|
Retainer |
1 |
InternKon: 944 860 40 / 1
|
|
|
|
32 |
944 862 40
|
Retainer |
1 |
InternKon: 944 860 40 / 2
|
|
|
|
33 |
944 863 40
|
Retainer |
1 |
InternKon: 944 860 40 / 3
|
|
|
|
34 |
944 866 40
|
Retainer |
1 |
InternKon: 944 860 40 / 4
|
|
|
|
35 |
944 867 40
|
Plate |
1 |
InternKon: 944 860 40 / 5
|
|
|
|
36 |
510 390 98
|
Pair of clamps |
6 |
InternBDB: L-2-R-18 /DIN 03015 | InternKon: 944 860 40 / 6
|
|
|
|
37 |
511 855 98
|
Cover plate |
6 |
InternBDB: L-2 /DIN 03015 | InternKon: 944 860 40 / 7
|
|
|
|
38 |
307 777 99
|
Bolt |
4 |
InternBDB: M10X 25 /DIN 00933 | InternKon: 944 860 40 / 8
|
|
|
|
39 |
308 539 99
|
Bolt |
12 |
InternBDB: M6X 55 /DIN 00931 | InternKon: 944 860 40 / 9
|
|
|
|
40 |
507 037 98
|
Nut |
4 |
InternBDB: M10 /DIN 00985 | InternKon: 944 860 40 / 10
|
|
|
|
41 |
507 025 98
|
Nut |
12 |
InternBDB: M 6 /DIN 00985 | InternKon: 944 860 40 / 11
|
|
|
|
42 |
340 465 99
|
Washer |
8 |
InternBDB: B 10,5 /DIN 00125 | InternKon: 944 860 40 / 12
|
|
|
|
43 |
340 463 99
|
Washer |
12 |
InternBDB: B 6,4 /DIN 00125 | InternKon: 944 860 40 / 13
|
|
|
|
44 |
371 276 99
|
Union nut |
12 |
InternBDB: N-L 18 /ISO 08434 | InternKon: 944 860 40 / 17
|
|
|
|
45 |
906 349 40
|
Olive |
12 |
InternBDB: ES-4 L18 /WN 65593940 | InternKon: 944 860 40 / 18
|
|
|
|
46 |
215 812 99
|
Tube 1058mm |
-2 |
InternBDB: 18x1,5 /DIN02391
|
|
|
|
47 |
215 812 99
|
Tube 983mm |
-2 |
InternBDB: 18x1,5 /DIN02391
|
|
|
|
48 |
215 812 99
|
Tube 842mm |
-2 |
InternBDB: 18x1,5 /DIN02391
|
|
|
|
51 |
795 726 73
|
Union piece |
2 |
InternBDB: 2.60.129
|
|
|
|
52 |
795 728 73
|
Union piece |
2 |
InternBDB: 2.060.236 | InternKon: 00X132-02 / 10
|
|
|
|
53 |
795 727 73
|
Union piece |
2 |
InternBDB: 2.060.234 | InternKon: 00X132-02 / 20
|
|
|
|
54 |
795 729 73
|
Union piece |
2 |
InternBDB: 2.060.237 | InternKon: 00X132-02 / 30
|
|
|
|
55 |
944 886 40
|
Retainer |
1 |
InternKon: 944 860 40 / 19
|
|
|
|
56 |
940 777 40
|
Screw plug w. fuel dip stick 1165mm |
2 |
InternBDB: M12x1,5 / Hunger | InternKon: 944 860 40 / 20
|
|
|
|
57 |
940 776 40
|
Screw plug w. fuel dip stick 1040mm |
2 |
InternBDB: M12x1,5 / Hunger | InternKon: 944 860 40 / 21
|
|
|
|
58 |
940 775 40
|
Screw plug w. fuel dip stick 898mm |
2 |
InternBDB: M12x1,5 / Hunger | InternKon: 944 860 40 / 22
|
|
