TRACK GROUP - DRIVE SPROCKET SIDE, R.H. AND L.H. | PC8000-6E S/N 12088

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

Diagram image 1 of 2

PC8000-6E S/N 12088

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC8000-6E S/N 12088

? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?		See Parts page Drive sprocket	2
?	358 603 40	Lifetime seal	4
?	313 346 40	Sleeve shaft	2
?	919 795 40	Drive shaft	2
?	911 595 40	Bearing, assy.	2
?	429 650 40	Bearing	2
?	922 984 40	Freeze-in bush	2
?	332 361 99	Nut (Standard)	24
?	501 132 98	Nut (Cold weather design)	24
?	517 548 98	Washer	24
?	308 340 99	Bolt (Standard)	24
?	501 131 98	Bolt (Cold weather design)	24
?	504 347 98	O-ring	2
?	429 270 40	Bearing cap	2
?	517 123 98	Lock washer	8
?	429 266 40	Bolt	8
?	339 907 99	Seal ring	4
?	313 267 99	Plug	2
?	929 429 40	Oil dip stick	2
?	505 111 98	O-ring	2
?	939 637 40	Bearing, assy.	2
?	948 956 40	Bearing	2
?	922 984 40	Freeze-in bush	2
?	502 213 98	Bolt (Standard)	24
?	510 516 98	Bolt (Cold weather design)	24
?	504 850 98	O-ring	2
?	518 418 98	Washer	90
?	505 380 98	Bolt (Standard)	88
?		Travelling gear motor	4	991-0080
?	307 847 99	Bolt (Standard)	32
?	500 536 98	Bolt (Cold weather design)	32
?	323 460 40	Vent valve	8
?		Travelling gear	2	991-0999
?	646 196 40	Protecting plate	2
?	308 377 99	Bolt	2
?	374 440 99	Socket	2
?	621 626 40	Sleeve	2
?	519 517 40	Cover	2
?	307 777 99	Bolt	8
?	517 122 98	Lock washer	8
