HYDRAULIK CYLINDER | PC8000-6E S/N 12087 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC8000-6E S/N 12087

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	926 800 40	Hydraulic cylinder, assy. fig nos: 03-37	1
?	798 083 73	Cylinder barrel, assy. fig-nos: 03-06	-2
?		Cylinder	1
?	960 217 40	Freeeze-in bush	2
?	907 028 40	Seal ring	4
?	004 860 98	Grease nipple	4
?	947 188 40	Thread pin	1
?	947 175 40	Groove nut	1
?	926 808 40	Piston, assy. fig-nos. 10 and 11 (finish work after bush is installed)	1
?		Piston	1
?	926 814 40	Piston bush	1
?	932 915 40	Piston guide strap	2
?	907 701 40	Piston guide ring	6
?	907 700 40	Sealing element	1
?	907 212 40	Support ring	2
?	517 018 98	O-ring	1
?	907 850 40	O-ring	1
?	907 851 40	Support ring	1
?	953 840 40	Sealing flange, assy. fig-nos. 21 and 22 (Finish work after bush is installed)	1
?	953 839 40	Bush	1
?	953 838 40	Bush	1
?	513 604 98	Bolt	26
?	516 852 98	Seal kit	1
?	906 999 40	Support ring	1
?	917 024 40	Cover	1
?	501 395 98	Bolt	24
?	938 873 40	Stripper	1
?	354 400 99	Feather key	1
?	794 791 73	Piston rod, assy. fig nos: 04-06, 29,31	1
?		Piston rod	1
?	907 000 40	Support ring	1
?	917 026 40	Cover ring	1
?	917 061 40	Half shim	16
?	794 792 73	Seal kit - piston fig nos: 12-17	1
?	794 793 73	Seal kit - sealing flnage fig: 18,19,24,25,28 and 35	1
?	798 280 73	Seal kit - sealing flnage fig: 18,19,24,25,28 and 35	1
