Diagram image 1 of 2

PC8000-6 S/N 12082

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC8000-6 S/N 12082

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	955 745 40	Cab support	1
?	908 220 40	Flap	2
?	390 199 40	Hinge concist. of fig. no 19-24	6
?	955 827 40	Door assy.	1
?	908 047 40	Cover	1
?	592 259 40	Profiled joint ca. 5000 lg.	1
?	500 873 98	Bolt	4
?	332 353 99	Nut	4
?	517 118 98	Lock washer	10
?	940 907 40	Fastener w/o lock pin	2
?	342 057 99	Spilt pin	1
?	946 184 40	Catch	1
?	952 828 40	Door SK	1
?	902 183 40	Seal	1
?	334 600 99	Nut	4
?	945 739 40	Seal	1
?	334 599 99	Nut	22
?	350 562 99	Grease nipple	1
?	621 108 40	Pin	1
?	390 600 40	Bushing	2
?	390 601 40	Bushing	1
?	340 612 99	Washer	2
?	342 061 99	Cotter pin	2
?	340 464 99	Washer	22
?	908 229 40	Cover	2
?	908 227 40	Cover	1
?	908 225 40	Cover	1
?	917 943 40	Cover	1
?	904 244 40	Cover	1
?	904 243 40	Seal	1
?	307 805 99	Bolt	6
?	955 718 40	Cover	1
?	534 017 99	Cover plate	6
?	308 555 99	Bolt	6
?	518 158 99	Clamp set	6
?	509 057 98	Clamp set	9
?	510 180 98	Clamp set	3
?	504 986 98	Screw	12
?	504 985 98	Locking plate	6
?	319 133 99	Screw	12
?	319 421 99	Bolt	46
?	941 444 40	Handle	1
?	941 445 40	Handle	1
?	941 563 40	Axle	1
?	941 447 40	Collar	1
?	941 450 40	Closing cam	1
?	941 451 40	Collar	1
?	941 449 40	Accessory ri.	1
?	940 485 40	Seal	2
?	940 486 40	Rail	4
?	906 759 40	Clamp 60	7
?	941 360 40	Clamp 30	4
?			-2
?			-2
