Diagram image 1 of 2

PC4000-6 S/N 58125

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC4000-6 S/N 58125

? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?		see page operator's cab	1
?	957 250 40	Stage	1
?	957 299 40	Rail	1
?	922 812 40	Rail	1
?	959 507 40	Rail	1
?	962 041 40	Door	1
?	956 952 40	Hinge, kpl. right	2
?	957 290 40	Grating	1
?	959 520 40	Grating	1
?	901 914 40	Grating	1
?	959 530 40	Grating	1
?	901 927 40	Grating	1
?	901 905 40	Adapter plate	4
?	913 139 40	Adaptor plate	2
?	913 141 40	Adaptor plate	2
?	901 855 40	Absorber	18
?	913 142 40	Angle	2
?	913 143 40	Angle	2
?	906 021 40	Grating 40x480x1590	2
?	510 728 98	Resilient sleeve	44
?	512 958 98	Resilient sleeve 13/25x45	72
?	308 886 99	Bolt	44
?	501 111 98	Bolt (Could weather design)	44
?	308 435 99	Bolt	72
?	516 576 98	Bolt (Could weather design)	72
?	332 353 99	Nut	72
?	516 577 98	Nut (Could weather design)	72
?	316 216 99	Washer	72
?	317 319 40	Threaded block	24
?	317 318 40	Wing nut, plastic	8
?	502 354 98	Bolt	8
?	307 757 99	Bolt	22
?	517 121 98	Lock washer	16
?	307 600 99	Bolt	2
?	340 467 99	Washer	12
?	334 599 99	Nut	12
?	959 533 40	Pipe	2
?	180 894 40	Plug	2
?	518 266 98	Clamp set	28
?	534 008 99	Cover plate	28
?	308 434 99	Bolt	56
?	518 200 98	Lock washer	56
?	517 122 98	Lock washer	8
?	307 775 99	Bolt	8
?	308 560 99	Bolt	4
?	340 464 99	Washer	16
?	365 761 40	Bolt	6
?	307 806 99	Bolt	4
?	334 600 99	Nut	5
?	956 950 40	Catch	1
?	308 608 99	Bolt	1
?	930 037 40	Rail pipe	1
?	930 031 40	Catch	1
?	517 697 98	Pin	1
?	340 605 99	Washer	1
?	342 045 99	Cotter pin	1
?	098 955 40	Ring	2
?	472 688 99	Chain	-2
?	308 444 99	Bolt (Standard)	21
?	513 033 98	Bolt (Could weather design)	21
?	510 730 98	Resilient sleeve 17/30x55	21
?	514 101 98	Bolt, Tool- 140mm	2
?	946 177 40	Retainer cpl.	2
?	081 474 40	Rubber hood retainer	2
?	655 730 40	Hose Ш13	-2
?	005 936 98	Hose clip	3
?	511 015 98	Union	1
?	906 347 40	Olive	3
?	371 274 99	Union nut	3
?	599 165 40	Pipe Ш12	-2
?	504 987 98	Clamp Set	5
?	319 132 99	Bolt	6
