RADIATOR | PC4000-6 S/N 58132 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC4000-6 S/N 58132

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	928 704 40	Radiator assy.	1
?	793 494 73	Radiator frame (HTC - Hi temp) assy consist. of fig. nr. 2, 6, 9, 11, 12, 17, 18, 19, 20, 23, 24,	1
?	793 495 73	Radiator frame (LTC - Low temp) assy consist. of fig. nr. 3, 6, 9, 11, 19, 20, 21, 22, 23, 24, 25,	1
?	768 965 73	Radiator frame	1
?	768 964 73	Radiator frame	1
?	769 772 73	Surge tank	1
?	769 773 73	Fan shroud	1
?	768 967 73	Pipe	920
?	768 972 73	Sight glass	1
?	768 968 73	Hose	3
?	769 778 73	Insulation strip	2
?	764 487 73	Fitting	6
?	769 777 73	Insulation stip	2
?	764 521 73	Clamp	2
?	764 489 73	Adapter	6
?	761 086 73	Tube pole cap	1
?	769 779 73	Hose	1
?	764 491 73	Clamp	3
?	793 497 73	Support bar	2
?	793 498 73	Support bar	2
?	780 314 73	Rubber seal	920
?	764 494 73	Rubber seal	920
?	768 974 73	Support bar	2
?	763 706 73	Support bar	2
?	768 969 73	Washer	52
?	768 971 73	Nut	44
?	768 970 73	Washer	4
?	502 313 98	Bolt	4
?	005 833 98	Bolt	52
?	004 869 98	Bolt	16
?	005 834 98	Bolt	6
?	793 493 73	Clasp	2
?	764 504 73	Nut	32
?	764 503 73	Nut	4
?	007 021 98	Nut	6
?	764 505 73	Nut	12
?	346 500 99	Lock washer	32
?	346 501 99	Lock washer	6
?	340 464 99	Washer	8
?	340 465 99	Washer	32
?	340 467 99	Washer	6
