AIR CONDITIONING UNIT | PC4000-6 S/N 58132 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
?	942 088 40	Air conditioning unit Diesel-shovel	1
?	942 050 40	Air conditioning unit Electro-shovel	1
?	797 800 73	Evaporator unit, incl. Pos.26	1
?	795 873 73	Condenser unit	1
?	797 808 73	Switch	1
?	793 251 73	Expansion valve	2
?	794 433 73	Collector bottle	1
?	794 432 73	Element drier	1
?	795 824 73	Check valve	1
?	792 547 73	Inspection glass	1
?	797 807 73	High pressure switch	1
?	792 548 73	Evaporator fan	2
?	794 709 73	Ventilator	2
?	793 252 73	Nozzle	2
?	795 825 73	Suction line, T-collector - compressor	1
?	795 826 73	Liquid line, collector - drier	1
?	795 827 73	Liquid line, condenser - collector	1
?	765 320 73	Clamp	1
?	795 828 73	Liquid line, drier - T-distributor	1
?	793 253 73	Pressure balance line	1
?	765 159 73	Base	8
?	795 829 73	Relay	1
?	795 830 73	Diode	1
?	795 831 73	Fuse box	1
?	797 918 73	Control section, Diesel shovel	1
?	796 053 73	Control section, Electro-shovel	1
?	794 570 73	Speed controller	2
?	797 398 73	Pipe set, Suction line - T-collector pipe	1
?	797 645 73	Liquid line, T-distributor - exp. Valves	1
?	797 801 73	Seal kit, to the air conditioning unit	-2
