CYLINDER HEAD(#11500-) | S6D170-1G-6A S/N 10001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

S6D170-1G-6A S/N 10001-UP

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	6162-13-1103	CYLINDER HEAD ASS'Y,VALVE LESS	6	SN: 17462-UP
?	6162-13-1102	CYLINDER HEAD ASS'Y,VALVE LESS	6	SN: 14209-17461
?	6162-13-1100	CYLINDER HEAD ASS'Y,VALVE LESS	6	SN: 11500-14208
?		HEAD,CYLINDER	1	SN: 11500-UP
?	6162-13-1130	SLEEVE	1	SN: 11500-UP
?	6162-12-1152	O-RING (K1)	1	SN: 11500-UP
?	6162-15-1370	INSERT,INTAKE VALVE (STD)	2	SN: 17462-UP
?	6162-13-1330	INSERT,INTAKE VALVE (STD)	2	SN: 11500-17461
?	6162-19-1370	INSERT, 0.25MM,INTAKE VALVE (OS)	2	SN: 17462-UP
?	6162-19-1330	INSERT, 0.25MM,INTAKE VALVE (OS)	2	SN: 11500-17461
?	6162-18-1370	INSERT, 0.50MM,INTAKE VALVE (OS)	2	SN: 17462-UP
?	6162-18-1330	INSERT, 0.50MM,INTAKE VALVE (OS)	2	SN: 11500-17461
?	6162-17-1370	INSERT, 0.75MM,INTAKE VALVE (OS)	2	SN: 17462-UP
?	6162-17-1330	INSERT, 0.75MM,INTAKE VALVE (OS)	2	SN: 11500-17461
?	6162-16-1370	INSERT, 1.00MM,INTAKE VALVE (OS)	2	SN: 17462-UP
?	6162-16-1330	INSERT, 1.00MM,INTAKE VALVE (OS)	2	SN: 11500-17461
?	6162-13-1322	INSERT,EXHAUST VALVE (STD)	2	SN: 12381-UP
?	6162-13-1321	INSERT,EXHAUST VALVE (STD)	2	SN: (12381-14208)
?	6162-13-1320	INSERT,EXHAUST VALVE (STD)	2	SN: 11500-12380
?	6162-19-1322	INSERT, 0.25MM,EXHAUST VALVE (OS)	2	SN: 12381-UP
?	6162-19-1321	INSERT, 0.25MM,EXHAUST VALVE (OS)	2	SN: (12381-14208)
?	6162-19-1320	INSERT, 0.25MM,EXHAUST VALVE (OS)	2	SN: 11500-12380
?	6162-18-1322	INSERT, 0.50MM,EXHAUST VALVE (OS)	2	SN: 12381-UP
?	6162-18-1321	INSERT, 0.50MM,EXHAUST VALVE (OS)	2	SN: (12381-14208)
?	6162-18-1320	INSERT, 0.50MM,EXHAUST VALVE (OS)	2	SN: 11500-12380
?	6162-17-1322	INSERT, 0.75MM,EXHAUST VALVE (OS)	2	SN: 12381-UP
?	6162-17-1321	INSERT, 0.75MM,EXHAUST VALVE (OS)	2	SN: (12381-14208)
?	6162-17-1320	INSERT, 0.75MM,EXHAUST VALVE (OS)	2	SN: 11500-12380
?	6162-16-1322	INSERT, 1.00MM,EXHAUST VALVE (OS)	2	SN: 12381-UP
?	6162-16-1321	INSERT, 1.00MM,EXHAUST VALVE (OS)	2	SN: (12381-14208)
?	6162-16-1320	INSERT, 1.00MM,EXHAUST VALVE (OS)	2	SN: 11500-12380
?	6162-16-1341	GUIDE,VALVE	4	SN: 11500-UP
?	6162-13-1160	TUBE,PUSH ROD	2	SN: 11500-UP
?	07000-73028	O-RING (K1)	2	SN: 20263-UP \| KIT-FLAG: S
?	07000-63028	O-RING (K1)	2	SN: 11500-20262
?	6162-13-1140	GUIDE,CROSSHEAD	2	SN: 11500-UP
?	07043-50108	PLUG	4	SN: 14209-UP
?	07043-50108	PLUG	3	SN: 11500-14208
?	07043-50211	PLUG	1	SN: 11500-UP
?	07043-50617	PLUG	5	SN: 11500-UP
?	6162-13-1150	PLUG,EXPANSION	12	SN: 13306-UP
?	6162-13-1150	PLUG,EXPANSION	11	SN: 11500-13305
?	6162-13-1410	PIN	2	SN: 11500-UP
?	6162-43-4111	VALVE,INTAKE	12	SN: 19576-UP
?	6162-43-4110	VALVE,INTAKE	12	SN: 11500-19575
?	6164-41-4211	VALVE,EXHAUST	12	SN: 14209-UP
?	6164-41-4210	VALVE,EXHAUST	12	SN: 11500-14208
?	6162-43-4440	SPRING,OUTER	24	SN: 19359-UP
?	6162-43-4410	SPRING,OUTER	24	SN: 11500-19358
?	6162-43-4420	SPRING,INNER	24	SN: 11500-UP
?	6162-43-4510	SEAT,SPRING	24	SN: 11500-UP
?	6240-41-4520	COTTER,VALVE	48	SN: 22205-UP
?	6162-42-4520	COTTER,VALVE	48	SN: 11500-22204
?	6162-43-4430	SEAT,SPRING	24	SN: 11500-UP
?	6162-43-5610	CROSSHEAD	12	SN: 11500-UP
?	6162-43-5641	SCREW	12	SN: 20487-UP
?	6162-43-5640	SCREW	12	SN: 11500-20486
?	6127-41-5630	NUT	12	SN: 11500-UP
?		STANDARD	-1
?	6162-13-1812	GASKET,HEAD (K1)	6	SN: 14061-UP \| KIT-FLAG: S
?	6162-17-1811	GASKET,HEAD (K1)	6	SN: 12100-14060
?	6162-13-1811	GASKET,HEAD (K1)	6	SN: 12000-12099
?	6162-13-1810	GASKET,HEAD (K1)	6	SN: 11500-11999
?	6162-13-1820	GROMMET,OIL	2	SN: 11500-UP
?	6162-13-1832	GROMMET,WATER	1	SN: 14061-UP
?	6162-13-1831	GROMMET,WATER	1	SN: 11500-14060
?		GROMMET,OIL	1	SN: 11500-UP
?	6162-13-1851	GROMMET,WATER	1	SN: 11500-UP
?	6162-13-1850	GROMMET,WATER	1	SN: (11500-14060)
?		OVERSIZE 0.40MM	-1
?	6162-19-1812	GASKET,HEAD	6	SN: 14061-UP
?	6162-19-1811	GASKET,HEAD	6	SN: 12100-14060
?	6162-19-1810	GASKET,HEAD	6	SN: 11500-12099
?	6162-19-1820	GROMMET,OIL	2	SN: 11500-UP
?	6162-19-1832	GROMMET,WATER	1	SN: 14061-UP
?	6162-19-1831	GROMMET,WATER	1	SN: 11500-14060
?	6162-19-1840	GROMMET,OIL	1	SN: 11500-UP
?	6162-19-1851	GROMMET,WATER	1	SN: 11500-UP
?	6162-19-1850	GROMMET,WATER	1	SN: (11500-14060)
?	6162-15-1610	BOLT,HEAD	36	SN: 18134-UP
?	6162-13-1611	BOLT,HEAD	36	SN: 12100-18133
?	6162-13-1610	BOLT,HEAD	36	SN: 11500-12099
?	6162-13-1620	WASHER	36	SN: 11500-UP
