S6D108-1G-6 S/N 10001-UP

Komatsu parts book diagram for S6D108-1G-6 S/N 10001-UP: FRONT COVER (WITH TACHOMETER OUTLET) (GEAR BOX 22X1.5)(#17248-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	6221-21-3231	PLATE,FRONT	1	SN: 17248-UP
	?	6221-21-3820	GASKET (K2)	1	SN: 17248-UP \| KIT-FLAG: S
	?	01435-00820	BOLT	4	SN: 17248-UP
	?	6136-21-3111	COVER,FRONT	1	SN: 17248-UP
	?	6136-21-3830	GASKET (K2)	1	SN: 17248-UP \| KIT-FLAG: S
	?	6136-21-3510	SEAL, FRONT (K2)	1	SN: 17248-UP \| KIT-FLAG: S
	?	01435-00875	BOLT	1	SN: 17248-UP
	?	01435-00865	BOLT	4	SN: 17248-UP
	?	01435-00855	BOLT	6	SN: 17248-UP
	?	01435-00885	BOLT	2	SN: 17248-UP
	?	01435-00890	BOLT	1	SN: 17248-UP
	?	6221-81-5910	PLATE	1	SN: 17248-UP
	?	6221-81-5980	GASKET	1	SN: 17248-UP \| KIT-FLAG: S
	?	01435-20820	BOLT	4	SN: 17248-UP
	?	6142-82-5112	BOX,GEAR	1	SN: 17248-UP
	?	07000-03050	O-RING (K2)	1	SN: 17248-UP \| KIT-FLAG: S
	?	01435-20614	BOLT	2	SN: 17248-UP
	?	6130-82-5260	CAP	1	SN: 17248-UP
	?	6130-82-5270	GASKET	1	SN: 17248-UP \| KIT-FLAG: S

Komatsu S6D108-1G-6 S/N 10001-UP parts catalog PDF

FRONT COVER (WITH TACHOMETER OUTLET) (GEAR BOX 22X1.5)(#17248-) (A2040-A2B4) in S6D108-1G-6 S/N 10001-UP. Diagram image and parts list.
