|$0 |
6211-11-1011
|
CYLINDER HEAD ASS'Y,WITH VALVE |
6 |
SN: 13913-16835
|
|
|
|
|$1 |
6211-11-1010
|
CYLINDER HEAD ASS'Y,WITH VALVE |
6 |
SN: 10001-13912
|
|
|
|
|$$3 |
|
(6211-11-1011,6210-41-5620(2)) |
-1 |
|
|
|
|
|$3 |
6211-11-1100
|
CYLINDER HEAD ASS'Y,VALVE LESS |
1 |
SN: 10001-16835
|
|
|
|
1 |
|
HEAD,CYLINDER |
1 |
SN: 10001-16835
|
|
|
|
2 |
6210-16-1340
|
GUIDE,VALVE |
4 |
SN: 10001-@
|
|
|
|
3 |
6210-11-1140
|
GUIDE,CROSSHEAD |
2 |
SN: 10001-@
|
|
|
|
4 |
04020-00820
|
PIN,DOWEL |
2 |
SN: 10001-@
|
|
|
|
5 |
07046-41810
|
PLUG |
1 |
SN: 10001-@
|
|
|
|
6 |
6162-13-1150
|
PLUG,EXPANSION |
12 |
SN: 10001-@
|
|
|
|
7 |
6210-11-1330
|
INSERT,INTAKE VALVE (STD) |
2 |
SN: 10001-@
|
|
|
|
7 |
6210-19-1330
|
INSERT, 0.25MM,INTAKE VALVE (OS) |
2 |
SN: 10001-@
|
|
|
|
7 |
6210-18-1330
|
INSERT, 0.50MM,INTAKE VALVE (OS) |
2 |
SN: 10001-@
|
|
|
|
7 |
6210-17-1330
|
INSERT, 0.75MM,INTAKE VALVE (OS) |
2 |
SN: 10001-@
|
|
|
|
7 |
6210-16-1330
|
INSERT, 1.00MM,INTAKE VALVE (OS) |
2 |
SN: 10001-@
|
|
|
|
8 |
6210-11-1320
|
INSERT,EXHAUST VALVE (STD) |
2 |
SN: 10001-16835
|
|
|
|
8 |
6210-19-1320
|
INSERT, 0.25MM,EXHAUST VALVE (OS) |
2 |
SN: 10001-16835
|
|
|
|
8 |
6210-18-1320
|
INSERT, 0.50MM,EXHAUST VALVE (OS) |
2 |
SN: 10001-16835
|
|
|
|
8 |
6210-17-1320
|
INSERT, 0.75MM,EXHAUST VALVE (OS) |
2 |
SN: 10001-16835
|
|
|
|
8 |
6210-16-1320
|
INSERT, 1.00MM,EXHAUST VALVE (OS) |
2 |
SN: 10001-16835
|
|
|
|
9 |
6210-11-1150
|
PIPE |
1 |
SN: 10001-@
|
|
|
|
10 |
07000-63025
|
O-RING (K1) |
1 |
SN: 10001-@
|
|
|
|
11 |
07043-50108
|
PLUG |
1 |
SN: 10001-@
|
|
|
|
12 |
6215-41-4110
|
VALVE,INTAKE |
2 |
SN: 13913-@
|
|
|
|
12 |
6210-41-4110
|
VALVE,INTAKE |
2 |
SN: 10001-13912
|
|
|
|
13 |
6215-41-4212
|
VALVE,EXHAUST |
2 |
SN: 13913-@
|
|
|
|
13 |
6215-41-4211
|
VALVE,EXHAUST |
2 |
SN: 13913-16835
|
|
|
|
13 |
6210-41-4210
|
VALVE,EXHAUST |
2 |
SN: 10001-13912
|
|
|
|
14 |
6210-41-4440
|
SPRING,INNER |
4 |
SN: 13913-@
|
|
|
|
14 |
6210-41-4410
|
SPRING,INNER |
4 |
SN: 10001-13912
|
|
|
|
15 |
6210-41-4430
|
SPRING,OUTER |
4 |
SN: 13913-@
|
|
|
|
15 |
6210-41-4420
|
SPRING,OUTER |
4 |
SN: 10001-13912
|
|
|
|
16 |
6210-41-4530
|
SEAT,LOWER |
4 |
SN: 10001-@
|
|
|
|
17 |
6210-41-4510
|
SEAT,UPPER |
4 |
SN: 10001-@
|
|
|
|
18 |
6136-41-4520
|
COTTER |
8 |
SN: 10001-@
|
|
|
|
19 |
6210-41-5620
|
CROSSHEAD |
12 |
SN: 13913-@
|
|
|
|
19 |
6210-41-5610
|
CROSSHEAD |
12 |
SN: 10001-13912
|
|
|
|
|$$38 |
|
(6210-41-5620,6215-41-4110(2), |
-1 |
|
|
|
|
|$$39 |
|
6215-41-4212(2)) |
-1 |
|
|
|
|
20 |
6210-41-5640
|
SCREW |
12 |
SN: 10001-@
|
|
|
|
21 |
6127-41-5630
|
NUT |
12 |
SN: 10001-@
|
|
|
|
22 |
6210-17-1813
|
GASKET,HEAD (K1) |
6 |
SN: 16817-@
|
|
|
|
22 |
6210-17-1812
|
GASKET,HEAD (K1) |
6 |
SN: 13759-16816
|
|
|
|
22 |
6210-17-1811
|
GASKET,HEAD (K1) |
6 |
SN: 11978-13758
|
|
|
|
22 |
6210-11-1811
|
GASKET,HEAD (K1) |
6 |
SN: 11570-11977
|
|
|
|
22 |
6210-11-1810
|
GASKET,HEAD (K1) |
6 |
SN: 10001-11569
|
|
|
|
23 |
6210-11-1820
|
GROMMET,OIL |
1 |
SN: 11978-@
|
|
|
|
24 |
6210-11-1830
|
GROMMET,OIL |
1 |
SN: 11978-@
|
|
|
|
25 |
6210-11-1840
|
GROMMET,OIL |
1 |
SN: 11978-@
|
|
|
|
26 |
6210-11-1962
|
GROMMET,WATER |
1 |
SN: 16817-@
|
|
|
|
26 |
6210-11-1961
|
GROMMET,WATER |
1 |
SN: 13759-16816
|
|
|
|
26 |
6210-11-1850
|
GROMMET,WATER |
1 |
SN: 11978-13758
|
|
|
|
27 |
6210-11-1952
|
GROMMET,WATER |
4 |
SN: 16817-@
|
|
|
|
27 |
6210-11-1951
|
GROMMET,WATER |
4 |
SN: 13759-16816
|
|
|
|
27 |
6210-11-1860
|
GROMMET,WATER |
4 |
SN: 11978-13758
|
|
|
|
28 |
6210-11-1610
|
BOLT |
36 |
SN: 10001-@
|
|
|
|
29 |
6150-81-9160
|
BOLT |
6 |
SN: 10001-@
|
|
