CYLINDER HEAD(#11883-) | SA12V140-1R-A S/N 10001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity	Options
\|1	6215-11-1300	CYLINDER HEAD ASS'Y	12	SN: 13113-UP
\|1	6212-11-1103	CYLINDER HEAD ASS'Y	12	SN: 11883-13112
1		HEAD,CYLINDER	1	SN: 13113-UP
\|1		HEAD,CYLINDER	1	SN: 11883-13112
2	6216-11-1330	INSERT,INTAKE VALVE (STD)	2	SN: 11883-UP
\|2	6216-19-1330	INSERT¤ 0.25MM,INTAKE VALVE (OS)	2	SN: 11883-UP
\|2	6216-18-1330	INSERT¤ 0.50MM,INTAKE VALVE (OS)	2	SN: 11883-UP
\|2	6216-17-1330	INSERT¤ 0.75MM,INTAKE VALVE (OS)	2	SN: 11883-UP
\|2	6216-16-1330	INSERT¤ 1.00MM,INTAKE VALVE (OS)	2	SN: 11883-UP
3	6215-11-1320	INSERT,EXHAUST VALVE (STD)	2	SN: 13113-UP
\|3	6210-11-1321	INSERT,EXHAUST VALVE (STD)	2	SN: 11883-13112
\|3	6215-19-1320	INSERT¤ 0.25MM,EXHAUST VALVE (OS)	2	SN: 13113-UP
\|3	6210-19-1321	INSERT¤ 0.25MM,EXHAUST VALVE (OS)	2	SN: 11883-13112
\|3	6215-18-1320	INSERT¤ 0.50MM,EXHAUST VALVE (OS)	2	SN: 13113-UP
\|3	6210-18-1321	INSERT¤ 0.50MM,EXHAUST VALVE (OS)	2	SN: 11883-13112
\|3	6215-17-1320	INSERT¤ 0.75MM,EXHAUST VALVE (OS)	2	SN: 13113-UP
\|3	6210-17-1321	INSERT¤ 0.75MM,EXHAUST VALVE (OS)	2	SN: 11883-13112
\|3	6215-16-1320	INSERT¤ 1.00MM,EXHAUST VALVE (OS)	2	SN: 13113-UP
\|3	6210-16-1321	INSERT¤ 1.00MM,EXHAUST VALVE (OS)	2	SN: 11883-13112
4	6212-16-1440	GUIDE,VALVE	4	SN: 11883-UP
5	6210-11-1150	PIPE	1	SN: 11883-UP
6	07000-73025	O-RING (K1)	1	SN: 12473-UP
\|6	07000-63025	O-RING (K1)	1	SN: 11883-12472
7	6162-13-1150	PLUG,EXPANSION	12	SN: 11883-UP
8	07046-41810	PLUG,EXPANSION	1	SN: 11883-UP
9	6215-81-9510	PLUG	1	SN: 13113-UP
\|9	07043-50108	PLUG	1	SN: 11883-13112
9A	6215-81-9710	O-RING	1	SN: 13113-UP
10	6210-11-1140	GUIDE,CROSSHEAD	2	SN: 11883-UP
11	04020-00820	PIN,DOWEL	2	SN: 11883-UP
12	6215-41-4110	VALVE,INTAKE	24	SN: 11883-UP
13	6215-41-4220	VALVE,EXHAUST	24	SN: 11883-UP
14	6212-41-4540	SEAL,VALVE STEM (K1)	48	SN: 11883-UP
15	6210-41-4530	SEAT,SPRING¤ LOWER	24	SN: 13113-UP
\|15	6210-41-4530	SEAT,SPRING¤ LOWER	48	SN: 11883-13112
15A	6215-41-4510	ROTATOR	24	SN: 13113-UP
16	6210-41-4510	SEAT,SPRING¤ UPPER	48	SN: 11883-UP
17	6210-41-4430	SPRING,OUTER	24	SN: 13113-UP
\|17	6210-41-4430	SPRING,OUTER	48	SN: 11883-13112
17A	6215-41-4410	SPRING,OUTER	24	SN: 13113-UP
18	6210-41-4440	SPRING,INNER	24	SN: 13113-UP
\|18	6210-41-4440	SPRING,INNER	48	SN: 11883-13112
18A	6215-41-4420	SPRING,INNER	24	SN: 13113-UP
19	6136-41-4520	COTTER,VALVE	96	SN: 11883-UP
20	6210-41-5620	CROSSHEAD	24	SN: 11883-UP
21	6210-41-5641	SCREW	24	SN: 12761-UP
\|21	6210-41-5640	SCREW	24	SN: 11883-12760
22	6162-43-5630	NUT	24	SN: 11883-UP
\|$$49		STANDARD	-1
23	6210-17-1814	GASKET,HEAD (K1)	12	SN: 13253-UP
\|23	6210-17-1813	GASKET,HEAD (K1)	12	SN: 11883-13252
24	6210-11-1820	GROMMET,OIL	1	SN: 11883-UP
25	6210-11-1831	GROMMET,OIL	1	SN: 13253-UP
\|25	6210-11-1830	GROMMET,OIL	1	SN: 11883-13252
26	6210-11-1840	GROMMET,OIL	1	SN: 11883-UP
27	6210-11-1962	GROMMET,WATER	1	SN: 11883-UP
28	6210-11-1952	GROMMET,WATER	4	SN: 11883-UP
28A	6210-11-1940	GROMMET,WATER	4	SN: 13253-UP
\|$$59		OVERSIZE 0.40MM	-1
23	6210-19-1814	GASKET,HEAD	12	SN: 13253-UP
\|23	6210-19-1813	GASKET,HEAD	12	SN: 11883-13252
24	6210-19-1820	GROMMET,OIL	1	SN: 11883-UP
25	6210-19-1831	GROMMET,OIL	1	SN: 13253-UP
\|25	6210-19-1830	GROMMET,OIL	1	SN: 11883-13252
26	6210-19-1840	GROMMET,OIL	1	SN: 11883-UP
27	6210-19-1962	GROMMET,WATER	1	SN: 11883-UP
28	6210-19-1952	GROMMET,WATER	4	SN: 11883-UP
28A	6210-19-1940	GROMMET,WATER	4	SN: 13253-UP
29	6210-11-1610	BOLT,HEAD	72	SN: 11883-UP
30	01438-01020	BOLT	12	SN: 11883-UP
31	01050-31016	BOLT	12	SN: 11883-UP
32	07003-01015	GASKET	12	SN: 11883-UP
