S4D95LE-3A-2 S/N 100001-UP

Komatsu parts book diagram for S4D95LE-3A-2 S/N 100001-UP: CYLINDER HEAD

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	6205-13-1600	CYLINDER HEAD ASS'Y,VALVE LESS	1	SN: 100001-UP
	?		HEAD,CYLINDER	1	SN: 100001-UP
	?	6204-19-1310	GUIDE,VALVE	8	SN: 100001-UP
	?	07046-41008	PLUG	4	SN: 100001-UP
	?	07046-41810	PLUG	9	SN: 100001-UP
	?	07046-42216	PLUG	3	SN: 100001-UP
	?	07046-42516	PLUG	11	SN: 100001-UP
	?	02720-40104	PLUG	1	SN: 100001-UP
	?	6207-41-4110	VALVE,INTAKE	4	SN: 100001-UP
	?	6204-41-4210	VALVE,EXHAUST	4	SN: 100001-UP
	?	6204-41-4510	SEAT,SPRING	8	SN: 100001-UP
	?	6204-41-4520	COTTER	16	SN: 100001-UP
	?	6204-41-4410	SPRING,VALVE	8	SN: 100001-UP
	?	6204-41-4541	SEAL,VALVE	8	SN: 100001-UP \| KIT-FLAG: S
	?	6204-41-4550	CAP,VALVE STEM	8	SN: 100001-UP
	?	6204-11-1840	GASKET,HEAD	1	SN: 100001-UP \| KIT-FLAG: S
	?	6204-13-1610	BOLT	17	SN: 100001-UP

Komatsu S4D95LE-3A-2 S/N 100001-UP parts catalog PDF

CYLINDER HEAD (A1010-A0A6) in S4D95LE-3A-2 S/N 100001-UP. Diagram image and parts list.
