HYDRAULIC CYLINDER | PC5500-6 S/N 15019 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC5500-6 S/N 15019

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	924 960 40	Hydraulic Cylinder consist. of fig-nos: 02-37	1
?		Cylinder assy. These parts are not sold separately	1
?	347 449 99	Thread pin	1
?	262 221 40	Groove nut	1
?	460 378 40	Piston assy. consist. of fig-nos: 06 and 07 (finish work after bush is installed)	1
?	284 159 40	Piston bush	1
?		Piston These parts are not sold separately	1
?	269 477 40	Piston slyding strip 915mm	2
?	256 153 40	Piston wear-ring	5
?	269 474 40	Seal	1
?	269 476 40	O-ring	1
?	256 715 40	Back-up ring	2
?	000 224 98	O-ring	1
?	007 631 98	O-ring	1
?	226 422 40	Support ring	1
?	913 954 40	Sealing flange consist. of fig-nos: 17-18 (finish work after bush is installed)	1
?		Bush These parts are not sold separately	1
?	430 979 40	Bush	1
?	516 205 98	Bolt	18
?	461 287 40	Seal kit	1
?	909 514 40	Cover- ring	1
?	319 289 99	Bolt	12
?	906 539 40	Scraper	1
?	354 389 99	Shim	1
?	793 100 73	Piston rod assy. consist. of fig-nos: 25, 28, 28, 29	1
?		Piston rod These parts are not sold separately	1
?	924 962 40	Freeze-in bush	2
?	004 860 98	Nipple	1
?	906 727 40	Support ring for stripper fig.no.24	1
?	909 513 40	Cover	1
?	430 969 40	Half shim	12
?	906 588 40	Support ring for stripper fig.no.20	1
?	696 625 73	Sealing kit for piston consist. of fig-nos: 08-13	-2
?	792 147 73	Sealing kit for sealing flange consist. of fig-nos: 14,15,20,24,31	-2
