CONTROL PLATE | PC5500-6 S/N 15019 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC5500-6 S/N 15019

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	654 494 40	Threefold Control plate assy.	1
?	654 493 40	Simple Control plate assy.	1
?	757 370 73	Plate	1
?	767 340 73	Plate	1
?	313 404 99	Plug	-2
?	762 511 73	Plug	-2
?	757 368 73	Pressure reducing valve	-2
?	767 341 73	4/3-Directional valve w/o orifice	-2
?	319 174 99	Srew	-2
?	505 866 98	Srew	-2
?	501 795 98	O-ring	-2
?	515 813 40	4/3-Directional valve with orifice	-2
?	490 705 40	Orifice 1,8	-2
?	766 292 73	4/3-Directional valve with orifice	-2
?	655 736 40	Orifice 2,8	-2
?	461 911 40	Threefold control plate assy.	1
?	655 433 40	Threefold control plate assy.	1
?	621 523 40	Single control plate assy.	1
?	757 895 73	Seal kit	-2
?	756 234 73	Seal kit	-2
?	653 775 40	Threefold control plate (s/no. 06 127) H 185 A	1
?	883 453 40	Threefold control plate (s/no. 78 140) H 285 A	1
?	883 455 40	Threefold control plate (s/no. 78 140) H 285 A	1
?	896 544 40	4-fold control plate (s/no. 12 030)	1
?	766 831 73	Plate	1
?	896 540 40	Single control plate (s/no. 12 030)	1
?	763 702 73	Plate	1
?	757 389 73	O-ring	-2
?	509 285 98	Screw	-2
?	655 166 40	4-fold control plate (s/no. 08 151)	1
?	763 808 73	Solenoid	-2
?	757 371 73	Junktion box fig-no. 08,12,13	1
?	770 715 73	Connecting Board	1
