01 |
420 030 40
|
Superstructure platform |
1 |
InternKon: 409 990 40 / 1
|
|
|
|
02 |
448 560 40
|
Counterweight |
1 |
InternBDB: 448 561 40 SK Stapu 11500 kg. | InternKon: 409 990 40 / 43
|
|
|
|
03 |
506 211 98
|
Bolt |
4 |
InternBDB: M42x310 /931 10.9 | InternKon: 409 990 40 / 69
|
|
|
|
04 |
501 716 98
|
Washer |
4 |
InternBDB: 43 /6916 | InternKon: 409 990 40 / 82
|
|
|
|
06 |
420 876 40
|
Pin |
1 |
InternKon: 409 990 40 / 25
|
|
|
|
07 |
289 929 40
|
Bush |
4 |
InternKon: 409 990 40 / 29
|
|
|
|
08 |
425 145 40
|
Battery cover |
1 |
InternKon: 409 990 40 / 6
|
|
|
|
09 |
425 175 40
|
Cover - tool box |
1 |
InternKon: 409 990 40 / 7
|
|
|
|
10 |
323 212 40
|
Lock |
2 |
InternBDB: NO.4476-F | InternKon: 409 990 40 / 99
|
|
|
|
11 |
166 575 40
|
Clamping section
Bulk ware, state length
required |
-2 |
InternBDB: GHE 4610048 | InternKon: 409 990 40 / 100
|
|
|
|
12 |
425 129 40
|
Pin
Bullclam bucket equipment |
2 |
InternKon: 425 130 40 / 2
|
|
|
|
13 |
425 131 40
|
Disk
Bullclam bucket equipment |
2 |
InternKon: 425 130 40 / 3
|
|
|
|
14 |
425 132 40
|
Disk
Bullclam bucket equipment |
2 |
InternKon: 425 130 40 / 4
|
|
|
|
15 |
335 156 99
|
Pin
Bullclam bucket equipment |
2 |
InternBDB: A20h9x145 / 1443 | InternKon: 425 130 40 / 6
|
|
|
|
16 |
342 071 99
|
Cotter pin
Bullclam bucket equipment |
2 |
InternBDB: 20x140 /94 | InternKon: 425 130 40 / 7
|
|
|
|
17 |
409 958 40
|
Shackle |
1 |
InternKon: 425 130 40 / 39
|
|
|
|
18 |
307 846 99
|
Bolt |
-2 |
InternBDB: M20x55 /933 | InternKon: 425 130 40 / 68
|
|
|
|
19 |
421 472 40
|
Pin
Backhoe equipment |
2 |
InternKon: 427 200 40 / 2
|
|
|
|
20 |
421 473 40
|
Disk
Backhoe equipment |
2 |
InternKon: 427 200 40 / 3
|
|
|
|
21 |
335 156 99
|
Pin
Backhoe equipment |
2 |
InternBDB: A20H9x145 / 1443 | InternKon: 427 200 40 / 5
|
|
|
|
22 |
342 071 99
|
Cotter pin
Backhoe equipment |
2 |
InternBDB: 20x140 /94 | InternKon: 427 200 40 / 6
|
|
|
|
23 |
409 957 40
|
Twist lock |
2 |
InternKon: 409 990 40 / 38
|
|
|
|
24 |
425 184 40
|
Cover |
1 |
InternKon: 409 990 40 / 55
|
|
|
|
25 |
307 773 99
|
Bolt |
7 |
InternBDB: M10x15 /933 | InternKon: 409 990 40 / 73
|
|
|
|
26 |
320 816 99
|
Screw |
6 |
InternBDB: AM5x10 /84 | InternKon: 409 990 40 / 97
|
|
|
|
27 |
346 509 99
|
Lock washer |
6 |
InternBDB: 5 /128 | InternKon: 409 990 40 / 98
|
|
|
|
28 |
420 104 40
|
Cover |
1 |
InternKon: 409 990 40 / 23
|
|
|
|
29 |
332 340 99
|
Nut |
2 |
InternBDB: M24 /934 | InternKon: 409 990 40 / 94
|
|
|
|
30 |
340 471 99
|
Washer |
1 |
InternBDB: 25 /125 | InternKon: 409 990 40 / 95
|
|
|
|
31 |
308 577 99
|
Bolt |
1 |
InternBDB: M10x50 /931 | InternKon: 409 990 40 / 113
|
|
|
|
32 |
346 500 99
|
Lock washer |
1 |
InternBDB: 10 /128 | InternKon: 409 990 40 / 86
|
|
|
|
33 |
420 198 40
|
Holding plate |
2 |
InternKon: 409 990 40 / 20
|
|
|
|
34 |
308 578 99
|
Bolt |
4 |
InternBDB: M10x55 /931 | InternKon: 409 990 40 / 89
|
|
|
|
35 |
332 113 99
|
Nut |
8 |
InternBDB: M10 /934 | InternKon: 409 990 40 / 91
|
|
|
|
36 |
425 141 40
|
Spacer sleeve 8x40x200 |
4 |
InternBDB: Gummi-schwarz aus 08227440 | InternKon: 409 990 40 / 54
|
|
|
|
37 |
427 288 40
|
Platform |
1 |
InternKon: 409 990 40 / 24
|
|
|
|
38 |
307 807 99
|
Bolt |
4 |
InternBDB: M12x45 /933 | InternKon: 409 990 40 / 70
|
|
|
|
39 |
332 334 99
|
Nut |
8 |
InternBDB: M12 /934 | InternKon: 409 990 40 / 92
|
|
