PC75-1 S/N 5000001-Up

Komatsu parts book diagram for PC75-1 S/N 5000001-Up: TRACK SHOE (L=500 MM)

? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	22E-32-11030	R.H. TRACK SHOE, ASSY.	1	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11040	L.H. TRACK SHOE, ASSY.	1	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11250	R.H. SHOE 500 mm	42	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11260	L.H. SHOE 500 mm	42	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11230	BOLT	168	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11240	NUT	168	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11100	TRACK SHOE, ASSY.	1	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11110	LINK, TRACK, R.H.	42	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11120	LINK, TRACK, L.H.	42	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11130	SPACER	2	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11140	BUSHING	1	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11150	PIN	1	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11160	BUSHING	41	SN: 5000001-5000042 \| SN: 5000050-5000055
	?	22E-32-11170	PIN	41	SN: 5000001-5000042 \| SN: 5000050-5000055

Komatsu PC75-1 S/N 5000001-Up parts catalog PDF

TRACK SHOE (L=500 MM) (3425) in PC75-1 S/N 5000001-Up. Diagram image and parts list.
