METERING VALVE | PC5500-6 S/N 15017 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
?	269 887 40	Metering valve, assy.	1
?	269 880 40	Metering valve, assy.	1
?	693 442	Body to fig-no: 01	1
?	693 443	Body to fig-no: 02	1
?	693 444	Adjusting screw	1
?	693 445	Nut	1
?	693 446	Screw plug	1
?		Seal These parts are not sold separately	2
?		Disk These parts are not sold separately	2
?		Seal ring These parts are not sold separately	1
?		Bolt with nut These parts are not sold separately	1
?		Disk These parts are not sold separately	2
?		Seal ring These parts are not sold separately	1
?		Piston These parts are not sold separately	1
?		Compression spring These parts are not sold separately	1
?		Spring retainer These parts are not sold separately	1
?		Seal ring These parts are not sold separately	1
?		Disk These parts are not sold separately	1
?		Seal ring These parts are not sold separately	1
?		Disk These parts are not sold separately	1
?		Piston These parts are not sold separately	1
?	693 517	Seal	1
?	693 500	Adapter bolt	1
?	693 501	Valve housing	1
?	693 502	Union	1
?	270 131 40	Metering valve assy.	1
?	697 845 73	Body to fig-no: 26	1
?	551 969 40	Metering valve assy.	1
?	764 009 73	Body to fig-no: 28	1
?	764 312 73	Spare metering valve to fig-nos. 01,02,26,28	1
?	764 780 73	Repair kit	1
