HYDRAULIC-MOTOR | PC5500-6 S/N 15017 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
?	358 666 40	Hydraulic-motor, assy.	1
?		Housing	1
?	319 156 99	Screw	2
?	343 856 99	Lock washer	6
?	319 438 99	Screw	4
?	753 651	Connection plate	1
?	950 365	O-ring	1
?	344 791 99	Pin	1
?	754 684	Transmission, assy. fig-nos: 10,17-30	1
?	754 685	Transmission, hydr. part, assy. fig-nos: 11-16	1
?	754 686	Control plate	1
?	754 687	Cylinder	1
?	754 688	Spring plate	1
?	753 659	Cup spring	4
?	753 660	Trunnion	1
?	754 689	Piston with piston ring	7
?	753 662	Screw, burnished	7
?	754 690	Withdrawal plate	1
?	753 666	Disk	1
?	754 691	Drive shaft with bearing set with fig-nos: 21-23,27	1
?		Roller bearing These parts are not sold separately	1
?		Race These parts are not sold separately	1
?		Roller bearing These parts are not sold separately	1
?	754 692	Shim ring 95x115x0,1	2
?	754 693	Shim ring 95x115x0,3	1
?	971 124	O-ring	1
?		Groove nut These parts are not sold separately	1
?	504 035 98	Shaft seal No field repair item	1
?	753 550	Cover No field repair item	1
?	342 673 99	Circlip	1
?	753 669	Cover, assy. with fig-no: 28	1
?	999 062	Seal kit, assy. fig-nos: 07,26,28	-2
?	973 125	Fluid sealing 50 ml to fig-no: 17	-2
?	989 946	Fluid sealing 50 ml (pipe thread)	-2
