A2126-A1A5 CONNECTING ROD AND PISTON | WB156-5 BACKHOE LOADER S/N A63001-UP

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
\|$0	6731-32-3110	ENGINE ROD ASSEMBLY	6
1	NSS	ROD, ENGINE CONNECTING	1
2	6731-32-3310	BOLT, CONNECTING ROD CAP	2
3	6731-32-3120	BUSHING	1
4	6731-32-3410	BEARING, CONNECTING ROD LOWER (STD)	6
5	6731-32-3400	BEARING, CONNECTING ROD UPPER (STD)	6
\|$6	6732-32-2130	KIT, ENGINE PISTON (STD)	6
6	NSS	PISTON, ENGINE	1
7	6731-42-4510	RING, RETAINING	2
8	6735-32-2070	SET, PISTON RING	1
9	6731-32-2410	PIN, PISTON	6
\|$28		SERVICE PARTS	-1
4	6731-32-3460	BEARING, CONNECTING ROD (0.25 MM OS)	-2
4	6731-32-3470	BEARING, CONNECTING ROD (0.50 MM OS)	-2
4	6731-32-3480	BEARING, CONNECTING ROD (0.75 MM OS)	-2
4	6731-32-3490	BEARING, CONNECTING ROD (1.00 MM OS)	-2
5	6731-32-3420	BEARING, CONNECTING ROD (0.25 MM OS)	-2
5	6731-32-3430	BEARING, CONNECTING ROD (0.50 MM OS)	-2
5	6731-32-3440	BEARING, CONNECTING ROD (0.75 MM OS)	-2
5	6731-32-3450	BEARING, CONNECTING ROD (1.00 MM OS)	-2
\|$20	6732-32-2140	KIT, ENGINE PISTON (0.50 MM OS)	-2
6	NSS	PISTON, ENGINE	1
7	6731-42-4510	RING, RETAINING	2
8	6732-32-2310	SET, PISTON RING	1
\|$24	6732-32-2150	KIT, ENGINE PISTON (1.00 MM OS)	-2
6	NSS	PISTON, ENGINE	1
7	6731-42-4510	RING, RETAINING	2
8	6732-32-2320	SET, PISTON RING	1
