ENGINE & MISCELLANEOUS INSTL | AFE42-J 630E S/N 32081-32084 MT. LEYSHON

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE42-J 630E S/N 32081-32084 MT. LEYSHON

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB7366	ALTERNATOR, BLOWER & EXCITER ASSM	1
?	TJ5933	ADAPTOR ASSM	1
?	VW5737	CAPSCREW - 5/8" - 11NC X 2"	16
?	VN9087	CAPSCREW - 5/8" - 11NC X 2 1/2"	12
?	WA0361	FLAT WASHER - 5/8"	28
?	TM3466	SHIM - .004 (4 HOLE)	4
?	TM3467	SHIM - .004 (3 HOLE)	4
?	TM3468	SHIM - .007 (4 HOLE)	4
?	TM3469	SHIM - .007 (3 HOLE)	4
?	TW6616	SHIM - .010 (4 HOLE)	12
?		ENGINE (ORDER FROM FACTORY)	1
?	VN3672	PIVOT, ENGINE	1
?	C1645	CAPSCREW - 3/4" - 10NC X 2 1/4"	4
?	C1542	LOCKWASHER - 3/4"	26
?	TM1312	PIN, PIVOT	1
?	VM3891	BUSHING, RUBBER	3
?	E1473	CAPSCREW - 1 1/4" - 7NC X 2 1/2"	2
?	YA1530	SUB-FRAME	1
?	TX4672	TRUNNION	1
?	TG7442	FITTING, TUBE	1
?	TZ1815	CRADLE - R.H.	1
?	TZ1816	CRADLE - L.H.	1
?	VN9077	CAPSCREW - 3/4" - 10NC X 2 1/4"	18
?	VN9079	CAPSCREW - 1" - 8NC X 2 1/4"	8
?	C1544	LOCKWASHER - 1"	8
?	E4477	CAPSCREW - 3/4" - 10NC X 1 3/4" (TAPERED HEAD)	12
?	VM6531	CAP, ENGINE MOUNT	2
?	TN1018	PLATE, RETAINING	2
?	E5222	NUT - 3/4" - 10NC	4
?	VW2236	SET SCREW - 3/4" - 10NC X 3"	4
?	TN1019	PIN	2
?	PB4177	RACE	2
?	CD8419	CLAMP	2
?	VC2195	WELD STUD - 3/8" - 16NC X 1"	2
?	C1521	NUT - 3/8" - 16NC	2
?	TG2563	CLAMP	2
?	DF3042	FLAT WASHER - 3/8"	2
?	C0312	LOCKWASHER - 3/8"	2
?	TW5833	HOSE	2
?	1283871H91	ALTERNATOR, BATTERY CHARGING (SEE INDEX)	1
?	VE3412	BELT, ALTERNATOR DRIVE	1
?	VS7692	ELEMENT, ENGINE LUBE OIL FILTER	5
?	VE3885	ELEMENT, WATER CORROSION RESISTOR	3
?	DA5420	CAPSCREW, SOCKET HEAD (1)	2
?	ED0928	BAR, BUS (1)	1
?	ED0929	BRACKET (1)	1
?	ED0931	SHRINK, SLEEVE (1)	1
?	TA7409	INSULATOR, STAND0OFF (1)	1
?		NOTE: (1) USED WITH 24 VOLT, 100 AMP ALTERNATOR.	65535
