Diagram image 1 of 3

PC8000-11 S/N 12117

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC8000-11 S/N 12117

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC8000-11 S/N 12117

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	964 043 40	Control- and filter plate SK	1
?		Valve block	1	612-1837a
?		Filter - oil cooler-water cooler	2	991-0953
?		Filter - transmission oil	1	991-0424b
?		Pressure relief valve	2	991-0470a
?	940 732 40	4/3-Directional spool valve	1
?	940 730 40	4/2-Directional spool valve	1
?	797 167 73	Solenoid for fig-no.6 and 7	-2
?	796 627 73	Sealkit	-2
?	180 325 40	Base plate	2
?	951 794 40	Pressure relief valve	1
?		Sealkit valve housing to fig no. 09	1
?		Sealkit cartridge to fig no. 09	1
?	950 439 40	Pressure relief valve	1
?	319 553 99	Bolt	2
?	304 322 99	Bolt	4
?	334 682 99	Nut	4
?	308 554 99	Bolt	8
?	308 579 99	Bolt	4
?	515 801 98	Resilient sleeve	8
?	607 492 40	Resilient sleeve	4
?	507 036 98	Nut	2
?	334 599 99	Nut	8
?	340 461 99	Washer	2
?	307 740 99	Bolt	4
?	507 025 98	Nut	9
?	340 463 99	Washer	8
?	307 734 99	Bolt	4
?	308 560 99	Bolt	4
?	340 464 99	Washer	4
?	514 340 98	Screw	8
?	941 777 40	Plate	1
?	174 411 40	Cable strap	2
?	951 796 40	Pressure reducing valve	1
?		Sealkit to fig no. 30	1
?		Sealkit to fig no. 30	1
?	202 980 40	Connector plate	1
?	513 102 98	Hose DN 10 x 700	1
?	497 217 40	Pipe Ш 30	2
?	210 880 40	Pipe Ш 30	1
?	918 368 40	Pipe Ш 28	1
?	215 424 99	Pipe Ш 12	-2
?	374 412 99	Socket	2
?	374 464 99	Socket	4
?	374 439 99	Socket	4
?	374 431 99	Socket	3
?	371 459 99	Socket	8
?	907 152 40	Union	9
?	516 161 98	Socket	4
?	516 166 98	Socket	2
?	516 157 98	Socket	9
?	516 971 98	Socket	2
?	516 746 98	Union	5
?	516 743 98	Socket	1
?	516 181 98	Socket	3
?	516 961 98	Union	2
?	516 174 98	Socket	5
?	516 167 98	Socket	1
?	516 962 98	Union	1
?	655 426 40	Union	1
?	373 694 99	Threaded union	1
?	516 192 98	Socket	2
?	516 193 98	Socket	2
?	576 181 40	Union	2
?	551 458 40	Union	2
?	906 798 40	Union	1
?	004 131 98	Test coupling	3
?	515 814 98	Test coupling	1
?	180 113 40	Plug	2
?	255 968 40	Plug	2
?	255 694 40	Plug	2
?	255 171 40	Plug	1
?	371 265 99	Nut	6
?	371 263 99	Union nut	3
?	371 278 99	Union nut	2
?	371 274 99	Union nut	20
?	906 352 40	Olive	6
?	906 350 40	Olive	2
?	906 347 40	Olive	20
?	509 267 98	Nut	1
?	918 369 40	Pipe Ш 16	1
?	307 728 99	Bolt	1
?	307 757 99	Bolt	4
?	319 261 99	Bolt	4
?	006 302 98	Clamp	2
?	907 151 40	Olive	2
?	371 460 99	Socket	2
?	515 363 98	Hose assy. DN 10x800	1

Komatsu PC8000-11 S/N 12117 parts catalog PDF

CONTROL- AND FILTER PLATE - PDG WITH PIPING (113-1833q) in PC8000-11 S/N 12117. Diagram image and parts list.
