AFP49-A thru E 530M S/N A30001-A30008 (DH627-0)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	566-06-14321	LAMP COMB REAR	1
?	566-06-14331	LAMP	1
?	566-06-14311	LAMP COMB REAR	1
?	08128-22400	LAMP BACKUP	1
?	736131C2	ALARM BACKUP	1
?	EF8635	BRACKET STR.	1
?	565-03-11270	CUSHION	2
?	01436-30800	C/S M8	2
?	EF7824	BRACKET STR.	1
?	EF8453	BRACKET STR.	1
?	MM0032	C/S M12 X 1.75	8
?	MM0705	F/W M12	10
?	MM0026	C/S M8 X 1.25	8
?	MM0460	F/W M8	12
?	MM0718	NUT M8	10
?	EF8835	BRACKET STR.	1
?	EF8833	BRACKET	1
?	PB9223	MAGNET ASSM.	1
?	PB9224	SWITCH PROXIMITY	1
?	MM0582	C/S M6 X 1.00	4
?	MM0022	C/S M8 X 1.25	2
?	MM0010	C/S M12 X 1.75	2

Komatsu AFP49-A thru E 530M S/N A30001-A30008 (DH627-0) parts catalog PDF

TAILIGHTS / BODY-UP INSTALLATION (50203) in AFP49-A thru E 530M S/N A30001-A30008 (DH627-0). Diagram image and parts list.
