1 |
PB5712
|
RESISTOR - DIODE |
2 |
|
|
|
|
2 |
C5747
|
CAPSCREW - 5/16" - 18NC X 3/4" |
6 |
|
|
|
|
3 |
C1538
|
LOCKWASHER - 5/16" |
6 |
|
|
|
|
4 |
C1520
|
NUT - 5/16" - 18NC |
6 |
|
|
|
|
5 |
SM1967
|
BOARD, DIODE |
1 |
|
|
|
|
5 |
SM3124
|
DIODE |
1 |
|
|
|
|
6 |
EC9335
|
HARNESS, DIODE BOARD |
1 |
|
|
|
|
7 |
TF6376
|
MACHINE SCREW - #10 - 24NC X 1 1/4" |
4 |
|
|
|
|
8 |
PB8634
|
SPACER, ZINC PLATED BRASS |
4 |
|
|
|
|
9 |
EC9334
|
INSULATOR, DIODE BOARD |
1 |
|
|
|
|
10 |
TM6610
|
PAD, TAPPED |
1 |
|
|
|
|
11 |
TC1231
|
LOCKWASHER - 3/8" |
2 |
|
|
|
|
12 |
TC1233
|
NUT - 3/8" - 16NC |
2 |
|
|
|
|
13 |
TZ5535
|
CABLE - LADDER LIGHT |
1 |
|
|
|
|
14 |
EC8883
|
HARNESS (INSTRUMENT PANEL TO REAR OF CONTROL CABINET) |
1 |
|
|
|
|
15 |
VC6241
|
SOLENOID VALVE, HORN (SEE UNDER CAB PIPING PG) |
1 |
|
|
|
|
16 |
EC6687
|
HARNESS (INSTRUMENT PANEL TO JUNCTION BOX) |
1 |
|
|
|
|
16 |
ED0336
|
HARNESS (INSTRUMENT PANEL TO JUNCTION BOX) |
1 |
|
|
|
|
17 |
SF9896
|
DISCONNECT, KNIFE |
2 |
|
|
|
|
18 |
VZ3250
|
DIODE |
1 |
|
|
|
|
19 |
EC6684
|
HARNESS |
1 |
|
|
|
|
20 |
YA2816
|
HARNESS, SHIFT CONSOLE |
1 |
|
|
|
|
21 |
TX3084
|
WIRE |
1 |
|
|
|
|
22 |
TF6924
|
CLAMP |
1 |
|
|
|
|
23 |
DF3042
|
FLAT WASHER - 3/8" |
1 |
|
|
|
|
24 |
VH9969
|
WELD STUD - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
25 |
C0312
|
LOCKWASHER - 3/8" |
3 |
|
|
|
|
26 |
C1521
|
NUT - 3/8" - 16NC |
3 |
|
|
|
|
27 |
EC9261
|
HARNESS, BRAKE VALVE |
1 |
|
|
|
|
28 |
C5774
|
LOCKWASHER - 1/4" |
8 |
|
|
|
|
29 |
VN9773
|
FLAT WASHER - 1/4" |
4 |
|
|
|
|
30 |
C3145
|
CAPSCREW - 1/4" - 20NC X 5/8" |
6 |
|
|
|
|
31 |
PB7004
|
ALARM MODULE ASSM (A.I.D.) |
1 |
|
|
|
|
31 |
VE3422
|
BOX (W/O CARDS) |
1 |
|
|
|
|
31 |
VS5162
|
COVER |
1 |
|
|
|
|
31 |
VE1407
|
KNOB |
1 |
|
|
|
|
31 |
VJ8805
|
CARD, FLASHER/COOLANT LEVEL |
1 |
|
|
|
|
31 |
VJ8806
|
CARD, TEMPERATURE |
1 |
|
|
|
|
31 |
VJ9023
|
CARD, DIODE (W/ SOUND) |
1 |
|
|
|
|
31 |
VJ9024
|
CARD, DIODE (W/O SOUND) |
1 |
|
|
|
|
31 |
PB5672
|
CARD, SINGLE TEMPERATURE LATCH |
1 |
|
|
|
|
31 |
TS0299
|
RESISTORS |
2 |
|
|
|
|
31 |
TY7846
|
HOUSING |
1 |
|
|
|
|
31 |
TZ0951
|
HOUSING, LEVEL |
1 |
|
|
|
|
32 |
CC6522
|
LOCKWASHER - #6 (INTERNAL TOOTH) |
2 |
|
|
|
|
33 |
VJ9025
|
CARD, HOT SWITCH INVERTER |
2 |
|
|
|
|
34 |
C1547
|
FLAT WASHER - 3/8" |
2 |
|
|
|
|
35 |
TZ5140
|
COVER |
1 |
|
|
|
|
36 |
720462
|
CLAMP |
2 |
|
|
|
|
37 |
VH9969
|
WELD STUD - 3/8" - 16NC X 3/4" |
3 |
|
|
|
|
38 |
C1546
|
FLAT WASHER - 1/4" |
2 |
|
|
|
|
39 |
H8136
|
CAPSCREW - 1/4" - 20NC X 1/2" |
2 |
|
|
|
|
40 |
TS0753
|
BRACKET |
1 |
|
|
|
|
41 |
TZ5126
|
BRACKET |
1 |
|
|
|
|
42 |
C1546
|
FLAT WASHER - 1/4" |
4 |
|
|
|
|
43 |
C3145
|
CAPSCREW - 1/4" - 20NC X 5/8" |
4 |
|
|
|
|
44 |
TX1817
|
HOUSING (1) |
1 |
|
|
|
|
45 |
VZ3250
|
DIODE (1) |
1 |
|
|
|
|
46 |
TZ0951
|
HOUSING (2) |
1 |
|
|
|
|
47 |
TS0299
|
RESISTOR (2) |
2 |
|
|
|
|
48 |
TY7846
|
HOUSING (2) |
1 |
|
|
|
|
NS|62 |
|
NOTE: (1) INCLUDED IN TY4850 BODY-UP BUZZER INSTL. |
65535 |
|
|
|
|
NS|63 |
|
(2) INSTALLED TO DISABLE COOLANT LEVEL AND ENGINE |
65535 |
|
|
|
|
NS|64 |
|
TEMPERATURE CIRCUITS IN A.I.D. BOX. DDEC CONTROLS |
65535 |
|
|
|
|
NS|65 |
|
THESE CIRCUITS. |
