HOIST & STEERING PUMP ASSM (PB8142) | AFE43-AR 685E S/N 32278 BLAIR ATHOL

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE43-AR 685E S/N 32278 BLAIR ATHOL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VS1845	COVER, END	1
?	VS1844	CAPSCREW	4
?	RK2090	CARTRIDGE KIT	1
?	WA1230	RING, BACKUP (1)	1
?	VD5067	O-RING (1)	1
?		RING, SEAL (1)	1
?	CD2109	O-RING (1)	1
?		PLATE, OUTLET SUPPORT (2)	1
?		O-RING (1)	4
?		RETAINER (1)	4
?		PLATE, SIDE (2)	2
?		ROTOR (2)	1
?	VF9255	VANE KIT (CONSISTS OF 10 VANES & 10 INSERTS)	1
?		RING (2)	1
?		PLATE, INLET SUPPORT (2)	1
?	VJ9477	MACHINE SCREW	2
?	VJ9478	PIN	2
?		HOUSING (2)	1
?	RK2078	CARTRIDGE KIT	1
?	VJ9494	MACHINE SCREW	2
?	VJ9495	PIN	2
?		PLATE, INLET SUPPORT (2)	1
?		O-RING (1)	4
?		RETAINER (1)	4
?	VJ9497	PLATE, SIDE (2)	2
?	VJ9498	ROTOR (2)	1
?	VS1294	VANE KIT (CONSISTS OF 10 VANES & 10 INSERTS)	1
?	VJ9499	RING (2)	1
?	VJ9500	PLATE, OUTLET SUPPORT (2)	1
?	VH7517	O-RING (1)	1
?		RING, SEAL (1)	1
?	TF5573	O-RING (2)	1
?	WA1233	RING, BACKUP (1)	1
?	VS0616	LOCKRING	1
?	SP1068	SNAP RING	1
?	C9809	BEARING	1
?	VE7069	SHAFT	1
?	VS1194	WASHER	1
?	VJ9192	SEAL, OIL	1
?		BODY (2)	1
?	RK2106	NOTE: (1) INCLUDED IN RK2106 SEAL KIT.	65535
?		(2) NOT SVCD SEPARATELY.	65535
