1 |
VW7989
|
INJECTOR, REAR (1) |
2 |
|
|
|
|
2 |
TA4411
|
INJECTOR, REAR (1) |
1 |
|
|
|
|
3 |
VW7990
|
CAP, PROTECTIVE |
13 |
|
|
|
|
4 |
VN9073
|
CAPSCREW - 3/8" - 16NC X 2 1/4" |
6 |
|
|
|
|
5 |
C0312
|
LOCKWASHER - 3/8" |
6 |
|
|
|
|
6 |
C1521
|
NUT - 3/8" - 16NC |
6 |
|
|
|
|
7 |
TA4406
|
MOUNT, INJECTORS |
1 |
|
|
|
|
8 |
TA4407
|
PLATE, COVER |
1 |
|
|
|
|
9 |
TA1232
|
SPACER |
2 |
|
|
|
|
10 |
C1625
|
CAPSCREW - 1/2" - 13NC X 4 1/4" |
2 |
|
|
|
|
11 |
C1613
|
CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
12 |
C1540
|
LOCKWASHER - 1/2" |
2 |
|
|
|
|
13 |
C5770
|
PLUG, PIPE - 3/8" |
1 |
|
|
|
|
14 |
TB8803
|
NIPPLE |
2 |
|
|
|
|
15 |
TF4633
|
ELBOW - 90 DEG |
1 |
|
|
|
|
16 |
HA5902
|
HOSE (TO GREASE SUPPLY) |
1 |
|
|
|
|
17 |
HA9445
|
HOSE (TO BOTTOM OF REAR SUSPENSION) |
2 |
|
|
|
|
18 |
SV7053
|
ADAPTOR, STRAIGHT (AT BOTTOM OF REAR SUSPENSION) |
2 |
|
|
|
|
19 |
HA9410
|
HOSE (TO TOP OF HOIST CYLINDERS) |
2 |
|
|
|
|
20 |
SV7053
|
ADAPTOR, STRAIGHT (AT TOP OF HOIST CYLINDERS) |
2 |
|
|
|
|
21 |
HA9442
|
HOSE (TO BOTTOM OF HOIST CYLINDERS) |
2 |
|
|
|
|
22 |
DC5608
|
NIPPLE (AT BOTTOM OF HOIST CYLINDERS) |
2 |
|
|
|
|
23 |
C1231
|
COUPLING (AT BOTTOM OF HOIST CYLINDERS) |
2 |
|
|
|
|
24 |
VH0596
|
ELBOW - 90 DEG (AT BOTTOM OF HOIST CYLINDERS) |
2 |
|
|
|
|
25 |
HA9439
|
HOSE (TO DRIVE AXLE PIVOT PIN) |
1 |
|
|
|
|
26 |
DL2660
|
ELBOW - 90 DEG (AT DRIVE AXLE PIVOT PIN) |
1 |
|
|
|
|
27 |
HA9432
|
HOSE (TO LEFT FRONT OF ANTI-SWAY BAR) |
1 |
|
|
|
|
28 |
CD3705
|
NIPPLE (AT LEFT FRONT OF ANTI-SWAY BAR) |
1 |
|
|
|
|
29 |
C1231
|
COUPLING (AT LEFT FRONT OF ANTI-SWAY BAR) |
1 |
|
|
|
|
30 |
VH0596
|
ELBOW - 90 DEG (AT L.H. OF ANTI-SWAY BAR) |
1 |
|
|
|
|
31 |
TF6925
|
CLAMP |
9 |
|
|
|
|
32 |
HA0511
|
HOSE (TO R.H. OF ANTI-SWAY BAR) |
1 |
|
|
|
|
33 |
CD3705
|
NIPPLE (AT R.H. OF ANTI-SWAY BAR) |
1 |
|
|
|
|
34 |
C1231
|
COUPLING (AT R.H. OF ANTI-SWAY BAR) |
1 |
|
|
|
|
35 |
VH0596
|
ELBOW - 90 DEG (AT R.H. OF ANTI-SWAY BAR) |
1 |
|
|
|
|
36 |
HA0511
|
HOSE (TO TOP OF RIGHT REAR SUSPENSION) |
1 |
|
|
|
|
37 |
HA0511
|
HOSE (TO TOP OF LEFT REAR SUSPENSION) |
1 |
|
|
|
|
38 |
VH0596
|
ELBOW - 90 DEG (AT TOP OF RIGHT REAR SUSPENSION) |
1 |
|
|
|
|
39 |
HA9408
|
HOSE (TO BODY PIVOT PINS) |
2 |
|
|
|
|
40 |
DL2660
|
FITTING, TUBE (AT BODY PIVOT PINS) |
2 |
|
|
|
|
NS|41 |
|
NOTE: (1) ORDER VS1974 INJECTOR ASSM |
65535 |
|
|
|
|
NS|42 |
|
FOR FIELD REPLACEMENT. |
65535 |
|
|
