1 |
|
ENGINE - 16V (149T1B) (ORDER FROM FACTORY) |
1 |
|
|
|
|
2 |
1283871H91
|
ALTERNATOR - 24V (SEE INDEX) |
1 |
|
|
|
|
3 |
VE4035
|
BELT, ALTERNATOR |
1 |
|
|
|
|
4 |
PB8974
|
ALTERNATOR & BLOWER ASSM |
1 |
|
|
|
|
5 |
TN1019
|
PIN |
2 |
|
|
|
|
6 |
VW2236
|
SET SCREW - 3/4" - 10NC X 3" |
4 |
|
|
|
|
7 |
E5222
|
JAM NUT - 3/4" - 10NC |
4 |
|
|
|
|
8 |
C1542
|
LOCKWASHER - 3/4" |
18 |
|
|
|
|
9 |
TN1018
|
PLATE |
2 |
|
|
|
|
10 |
PB4177
|
RACE, INNER |
2 |
|
|
|
|
11 |
C1544
|
LOCKWASHER - 1" |
8 |
|
|
|
|
12 |
D1784
|
CAPSCREW - 1" - 8NC X 2 1/2" |
8 |
|
|
|
|
13 |
VM6531
|
CAP |
2 |
|
|
|
|
14 |
E4477
|
CAPSCREW, TAPERHEAD - 3/4" - 10NC X 1 1/32" |
12 |
|
|
|
|
15 |
TZ1812
|
CRADLE - R.H. |
1 |
|
|
|
|
15 |
TZ1813
|
CRADLE - L.H. |
1 |
|
|
|
|
16 |
C1630
|
CAPSCREW - 5/8" - 11NC X 2" |
8 |
|
|
|
|
17 |
C1541
|
LOCKWASHER - 5/8" |
8 |
|
|
|
|
18 |
TX4671
|
TRUNNION, ENGINE |
1 |
|
|
|
|
19 |
YA1530
|
FRAME, SUB |
1 |
|
|
|
|
20 |
C1645
|
CAPSCREW - 3/4" - 10NC X 2 1/4" |
4 |
|
|
|
|
21 |
VN3672
|
PIVOT |
1 |
|
|
|
|
22 |
VM3891
|
BUSHING |
3 |
|
|
|
|
23 |
TM1312
|
PIN, PIVOT |
1 |
|
|
|
|
24 |
E1473
|
CAPSCREW - 1 1/4" - 7NC X 2 1/2" |
2 |
|
|
|
|
25 |
C1645
|
CAPSCREW - 3/4" - 10NC X 2 1/4" |
4 |
|
|
|
|
26 |
C1644
|
CAPSCREW - 3/4" - 10NC X 2" |
6 |
|
|
|
|
27 |
TM5149
|
HOSE |
3 |
|
|
|
|
28 |
CD9707
|
CLAMP, WORM DRIVE |
3 |
|
|
|
|
29 |
TF6924
|
CLAMP, VINYL |
3 |
|
|
|
|
30 |
SR6310
|
CAPSCREW - 7/16" - 14NC X 3/4" |
3 |
|
|
|
|
31 |
C5775
|
LOCKWASHER - 7/16" |
3 |
|
|
|
|
32 |
|
ADAPTOR ASSM (PART OF ALTERNATOR & BLOWER ASSM) |
1 |
|
|
|
|
32 |
WA0361
|
FLAT WASHER - 5/8" |
5 |
|
|
|
|
32 |
VW5737
|
CAPSCREW - 5/8" - 11NC X 2" |
10 |
|
|
|
|
32 |
C9771
|
NUT - 5/8" - 11NC |
6 |
|
|
|
|
32 |
TM3466
|
SHIM - .004 (4 HOLE) |
12 |
|
|
|
|
32 |
TM3468
|
SHIM - .007 (4 HOLE) |
8 |
|
|
|
|
32 |
TM3467
|
SHIM - .004 (3 HOLE) |
4 |
|
|
|
|
32 |
TM3469
|
SHIM - .007 (3 HOLE) |
4 |
|
|
|
|
32 |
TW6616
|
SHIM - .010 (4 HOLE) |
12 |
|
|
|
|
33 |
VH4272
|
FITTING, ELBOW 45 DEG |
2 |
|
|
|
|
34 |
VM4249
|
HOSE |
2 |
|
|
|
|
35 |
VW5680
|
TEE, ADAPTOR (LEFT SIDE ONLY) |
1 |
|
|
|
|
36 |
VM4209
|
HOSE (LEFT SIDE ONLY) |
1 |
|
|
|
|
37 |
TD9743
|
BUSHING, PIPE |
2 |
|
|
|
|
38 |
DA5420
|
CAPSCREW, SOCKET HEAD (1) |
2 |
|
|
|
|
39 |
ED0928
|
BAR, BUS (1) |
1 |
|
|
|
|
40 |
ED0929
|
BRACKET (1) |
1 |
|
|
|
|
41 |
ED0931
|
SHRINK, SLEEVE (1) |
1 |
|
|
|
|
42 |
TA7409
|
INSULATOR, STAND-OFF (1) |
1 |
|
|
|
|
43 |
EC9977
|
WIRE, GROUND (1) |
1 |
|
|
|
|
44 |
VD6174
|
CLAMP |
2 |
|
|
|
|
45 |
TF6925
|
CLAMP, VINYL |
2 |
|
|
|
|
46 |
C1521
|
NUT - 3/8" - 16NC |
2 |
|
|
|
|
47 |
C1602
|
CAPSCREW - 3/8" - 16NC X 1" |
2 |
|
|
|
|
48 |
C1547
|
FLAT WASHER - 3/8" |
2 |
|
|
|
|
48 |
VE6356
|
ELEMENT, LUBE OIL FILTER (SPIN-ON) |
6 |
|
|
|
|
48 |
VE7356
|
FILTER, WATER CORROSION |
2 |
|
|
|
|
NS|60 |
|
NOTE: (1) USED WITH 24V, 100 AMP ALTERNATOR. |
