FRONT SPINDLE, HUB & BRAKE INSTL | AFE43-AR 685E S/N 32278 BLAIR ATHOL

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE43-AR 685E S/N 32278 BLAIR ATHOL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EB3031	SPINDLE, HUB & BRAKE ASSM	2
?	WA2953	STUD - 1" - 14UNS X 6 1/2"	35
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	C1540	LOCKWASHER - 1/2"	8
?	WA4795	SEAL, O-RING (2)	1
?	TY2126	COVER	1
?	H6881	PLUG, PIPE	1
?	TH6916	VALVE, CHECK	1
?	VN2458	CAPSCREW - 1" - 8NC X 3 1/2"	6
?	WA0364	FLAT WASHER - 1"	36
?	TY2134	RETAINER, BEARING	1
?	TY2135	SHIM - .002 (2)	7
?	TY2136	SHIM - .014 (2)	2
?	TY2137	SHIM - .031 (2)	2
?	PB6179	CONE, BEARING (2)	1
?	PB6178	CUP, BEARING (2)	1
?	EB1725	WHEEL HUB - 57"	1
?	WA4682	CAPSCREW	18
?	PB7362	DISC BRAKE ASSM (SEE INDEX)	3
?	TY6048	BRAKE, ADAPTOR	1
?	VN7703	NUT - 1" - 14NF	18
?	VM8258	CAPSCREW - 1" - 8NC X 3 3/4"	12
?	EC9920	SPINDLE	1
?	PB7008	CUP, BEARING (2)	1
?	PB7007	CONE, BEARING (2)	1
?	TX0805	TUBE	1
?	WA0362	FLAT WASHER - 3/4"	4
?	TH7593	ELBOW - 90 DEG	1
?	720462	CLAMP	1
?	WA0720	FLAT WASHER - 3/4"	1
?	HE5611	LOCKNUT - 3/4" - 10NC	1
?	DC7524	CAPSCREW - 3/4" - 10NC X 7/8"	1
?	TX0807	ANGLE	1
?	TF5190	CONNECTOR	1
?	TX0808	BOSS	1
?	TY8313	SPACER, BEARING	1
?	PB5756	SEAL (2)	1
?	WA4817	CAPSCREW - 1 1/4" - 12NF X 5"	24
?	TY2149	FLAT WASHER	54
?	WA4818	CAPSCREW - 1 1/4" - 12NF X 4"	30
?	TY6050	DISC, BRAKE	1
?	VM0315	PLUG, O-RING	1
?	WA3145	PLUG	1
?	PB7454	GAUGE, SIGHT W/ BALL	1
?	SD5211	BUSHING	1
?	PB6594	HUBODOMETER (1)	1
?	TX4849	PLATE, MOUNTING (1)	1
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4" (1)	2
?	TR4436	FLAT WASHER - 3/8" (1)	2
?		NOTE: (1) INCL IN BD0492 HUBODOMETER OPTION (KILOMETERS).	65535
?		(2) INCLUDED IN AK7135 SPINDLE MAINTENANCE KIT.	65535
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY)	65535
