HOIST FILTER PIPING & INSTALLATION | AFE78-X 930E-5 S/N A40089 IOCC

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE78-X 930E-5 S/N A40089 IOCC

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VC6561	CAPSCREW - 1/2" - 13NC X 1 1/2"	24
?	TR5445	LOCKWASHER - 1/2"	24
?	TF3231	CLAMP, SPLIT FLANGE - 2"	12
?	WA0187	O-RING	10
?	HA7908	HOSE	1
?	HA8311	HOSE	1
?	VM0319	PLUG	1
?	58F-09-00330	CAPSCREW - 1/2" - 13NC X 3 1/2"	4
?	PB8318	ELBOW	2
?	58F-60-00990	FILTER (1) (SEE FIG 68208)	2	68208
?	58F-60-10960	PLATE	1
?	VC1387	CAPSCREW - 1/2" - 13NC X 1"	4
?	TR6008	FLAT WASHER - 1/2"	12
?	VC6500	CAPSCREW - 1/2" - 13NC X 2"	4
?	HA7906	HOSE	1
?	58F-60-10950	HOSE	1
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	4
?	PC2057	WASHER, HEAD	4
?	WA2586	MOUNT, RUBBER	4
?	PC2058	WASHER, TAIL	4
?	TR6643	NUT - 1/2" - 13NC	4
?	EM7998	BLOCK, ADAPTER	1
?		NOTE: (1) NOT SERVICED AS AN ASSEMBLY.	-1
?		ORDER INDIVIDUAL COMPONENT PARTS.	-1
