|$1 |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
|
|
1 |
58F-32-00251
|
HUB ASSEMBLY |
1 |
|
|
|
|
1 |
58F-32-00001
|
HUB, WHEEL |
1 |
|
|
|
|
2 |
EH0826
|
STUD W/ HEAD |
57 |
|
|
|
|
3 |
EH7192
|
O-RING (1) |
1 |
|
|
|
|
4 |
EL2876
|
SHIM - .005" |
3 |
|
|
|
|
5 |
EL2877
|
SHIM - .007" |
4 |
|
|
|
|
6 |
EL2878
|
SHIM - .020" |
6 |
|
|
|
|
7 |
58F-32-00221
|
COVER |
1 |
|
|
|
|
8 |
WB1199
|
PLUG, MAGNETIC |
1 |
|
|
|
|
9 |
EH7190
|
O-RING (1) |
1 |
|
|
|
|
10 |
XB7696
|
RETAINER, BEARING |
1 |
|
|
|
|
11 |
TY2148
|
FLAT WASHER, HARDENED - 1" |
8 |
|
|
|
|
12 |
VM8258
|
CAPSCREW - 1" - 8NC X 3 3/4" |
8 |
|
|
|
|
13 |
PC3060
|
BEARING ASSEMBLY, OUTER (1) |
1 |
|
|
|
|
14 |
C1540
|
LOCKWASHER - 1/2" |
12 |
|
|
|
|
15 |
C1614
|
CAPSCREW - 1/2" - 13NC X 1 1/2" |
12 |
|
|
|
|
16 |
EH7195
|
O-RING (1) |
1 |
|
|
|
|
17 |
ED3755
|
SHIM - .020" |
54 |
|
|
|
|
18 |
EJ7475
|
GEAR, SPEED SENSOR |
1 |
|
|
|
|
19 |
58F-32-00201
|
SPINDLE |
1 |
|
|
|
|
20 |
PC3059
|
BEARING ASSEMBLY, INNER (1) |
1 |
|
|
|
|
21 |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
22 |
ED3772
|
SPACER, BEARING |
1 |
|
|
|
|
23 |
TY2149
|
FLAT WASHER, HARDENED - 1 1/4" |
89 |
|
|
|
|
24 |
WA5660
|
CAPSCREW, 12 PT - 1 1/4" - 12NF X 7 1/2" |
32 |
|
|
|
|
25 |
EH7194
|
O-RING (1) |
1 |
|
|
|
|
26 |
WA5669
|
CAPSCREW, 12 PT - 1 1/4" - 12NF X 3 1/2" |
57 |
|
|
|
|
27 |
EH7196
|
O-RING (1) |
1 |
|
|
|
|
28 |
ED3775
|
ADAPTER, BRAKE |
1 |
|
|
|
|
29 |
WA0360
|
FLAT WASHER, HARDENED - 1/2" |
24 |
|
|
|
|
30 |
VN9065
|
CAPSCREW - 1/2" - 13NC X 2" |
12 |
|
|
|
|
31 |
58F-32-00193
|
FRONT BRAKE ASSEMBLY (SEE INDEX) |
1 |
|
62918 |
|
|
32 |
569-33-81241
|
ADAPTER |
1 |
|
|
|
|
33 |
C1613
|
CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
34 |
58C-32-00451
|
TANK, CATCHMENT |
1 |
|
|
|
|
35 |
07002-52034
|
O-RING (1) |
1 |
|
|
|
|
36 |
58B-33-00011
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
37 |
PC1431
|
SEAL, OIL (1) |
1 |
|
|
|
|
38 |
58F-33-00181
|
CARRIER, SEAL |
1 |
|
|
|
|
39 |
58F-32-50001
|
BRACKET, MOUNTING |
6 |
|
|
|
|
40 |
D2930
|
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" |
6 |
|
|
|
|
41 |
C1612
|
CAPSCREW - 1/2" - 13NC X 1" |
12 |
|
|
|
|
42 |
PB7454
|
GAUGE, SIGHT |
1 |
|
|
|
|
43 |
58F-32-00151
|
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
44 |
58F-32-00170
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
45 |
58F-32-00161
|
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
46 |
DF6928
|
CAPSCREW - 1/2" - 13NC X 1 3/4" |
16 |
|
|
|
|
47 |
H8402
|
PLUG - 3/8" |
1 |
|
|
|
|
48 |
TH6916
|
VALVE, CHECK |
1 |
|
|
|
|
49 |
58F-22-00850
|
VENT, BREATHER (1) |
2 |
|
|
|
|
50 |
58F-32-00180
|
O-RING (1) |
1 |
|
|
|
|
51 |
07000-52018
|
O-RING (1) |
1 |
|
|
|
|
52 |
ED3756
|
SHIM - .010" |
6 |
|
|
|
|
53 |
EH7193
|
O-RING (1)/(2) |
1 |
|
|
|
|
NS|56 |
58F-SM-AK060
|
NOTE: (1) INCLUDED IN 58F-SM-AK060 SPINDLE |
-1 |
|
|
|
|
NS|57 |
|
MAINTENANCE KIT. |
-1 |
|
|
|
|
NS|58 |
|
(2) NOT INCLUDED IN ASSEMBLY. |
-1 |
|
|
