AFE78-S 930E-5 S/N A40078 - A40079 BOLIDEN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-54-60940	PLATFORM, RH	1
?	EM9230	PLATE, COVER	1
?	MM0606	CAPSCREW - M10 X 1.50 X 30	4
?	MM0471	LOCKWASHER - M10	12
?	MM0461	FLAT WASHER - M10	14
?	MM0459	FLAT WASHER - M6	4
?	58F-80-05040	COVER, SWITCH	1
?	58F-80-05540	PLATE	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	3
?	MM0711	FLAT WASHER, HARDENED - M6	3
?	58B-54-04840	BUMPER	2
?	58B-09-00200	CAPSCREW - M6 X 1.00 X 25	4
?	58E-54-18570	MOUNT, LADDER	1
?	58E-09-10110	BUSHING	2
?	TD1230	RING, RETAINER	4
?	58E-09-10120	PIN	2
?	SL8698	RING, RETAINER	4
?	07020-00001	FITTING, GREASE	2
?	XB5184	SEAT	2
?	58E-54-18950	SPACER	4
?	58E-06-13190	BUTTON, PUSH-PULL	1
?	VP4693	GROMMET	1
?	MM0610	CAPSCREW - M10 X 1.50 X 50	1
?	EM1398	SPACER	1
?	58B-54-01810	PLATE, COVER	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25	10
?	01315-20612	SCREW	4
?	58B-06-20020	BRACKET	1

Komatsu AFE78-S 930E-5 S/N A40078 - A40079 BOLIDEN parts catalog PDF

PLATFORM ASSEMBLY 1/2 58E-54-60930 (68991) in AFE78-S 930E-5 S/N A40078 - A40079 BOLIDEN. Diagram image and parts list.
