AFE77-AB 830E-5 S/N A50077 - A50078 DOWNER EDI

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EJ9909	CLAMP	8
?	WA4728	FLAT WASHER, HARDENED - 1/2"	32
?	DF3500	LOCKNUT - 1/2" - 13NC	16
?	WA0471	CAPSCREW - 1/2" - 13NC X 2 1/4"	5
?	VC4898	CAPSCREW - 1/2" - 13NC X 2 1/2"	8
?	TL8151	JAM NUT - 1/2" - 20NF	16
?	PC1247	ROD END, FEMALE	16
?	EK2341	ROD, THREADED	3
?	VC1390	LOCKWASHER - 5/8"	17
?	58F-09-00450	CAPSCREW - 5/8" - 11NC X 4 1/2"	13
?	WA4729	FLAT WASHER, HARDENED - 5/8"	13
?	TB1018	RAIN GUARD, SIDE	1
?	TB1406	RAIN GUARD, FRONT	1
?	TR2961	CAPSCREW - 5/8" - 11NC X 1"	4
?	TR9082	FLAT WASHER - 5/8"	4
?	58F-02-00160	AIR CLEANER ASSEMBLY, DUAL	1
?	VW7882	HOSE	1
?	WB1177	CLAMP, T-BOLT	12
?	TX6040	ELBOW, RUBBER - 45 DEG	1
?	WB1179	CLAMP, T-BOLT	4
?	EJ9919	BRACKET, MOUNTING	1
?	MM0616	CAPSCREW - M12 X 1.75 X 20	4
?	MM0714	FLAT WASHER, HARDENED - M12	4
?	TB1019	RAIN GUARD, SIDE	1
?	EJ9920	BRACKET, MOUNTING	1
?	EK1647	ROD, THREADED	1

Komatsu AFE77-AB 830E-5 S/N A50077 - A50078 DOWNER EDI parts catalog PDF

AIR CLEANER PIPING & INSTALLATION - RH 1/2 (69985) in AFE77-AB 830E-5 S/N A50077 - A50078 DOWNER EDI. Diagram image and parts list.
