SAA6D125E-5ER S/N 579001-UP (For WA480-6R)

? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Options
?	6251-31-2510	Piston	6	SN: 579001-UP
?	6151-31-2410	Pin, Piston	6	SN: 579001-UP
?	04065-04818	Ring, Snap	12	SN: 579001-UP
?	6251-31-2030	Piston Ring Assembly, Per Cylinder	6	SN: 579001-UP
?		Ring, Top	1	SN: 579001-UP \| SCC: C1
?		Ring, Second	1	SN: 579001-UP \| SCC: C1
?		Ring, Oil	1	SN: 579001-UP \| SCC: C1
?	6251-31-3100	Connecting Rod Assembly	6	SN: 579001-UP
?		Rod, Connecting	1	SN: 579001-UP \| SCC: C1
?		Cap, Connecting Rod	1	SN: 579001-UP \| SCC: C1
?	6251-31-3130	Bushing	1	SN: 579001-UP \| SCC: C3
?	6150-31-3310	Bolt	2	SN: 579001-UP
?	02400-10413	Pin, Dowel	2	SN: 579001-UP
?	6151-31-3050	Metal Assembly, Standard	6	SN: 579001-UP
?	6151-39-3050	Metal Assembly, Undersize, 0.25mm	6	SN: 579001-UP
?	6151-38-3050	Metal Assembly, Undersize, 0.50mm	6	SN: 579001-UP
?	6151-37-3050	Metal Assembly, Undersize, 0.75mm	6	SN: 579001-UP
?	6151-36-3050	Metal Assembly, Undersize, 1.00mm	6	SN: 579001-UP
?		Metal, Upper, Standard	6	SN: 579001-UP \| SCC: C1
?		Metal, Upper, Undersize, 0.25mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Upper, Undersize, 0.50mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Upper, Undersize, 0.75mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Upper, Undersize, 1.00mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Lower, Standard	6	SN: 579001-UP \| SCC: C1
?		Metal, Lower, Undersize, 0.25mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Lower, Undersize, 0.50mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Lower, Undersize, 0.75mm	6	SN: 579001-UP \| SCC: C1
?		Metal, Lower, Undersize, 1.00mm	6	SN: 579001-UP \| SCC: C1
?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
?		[C3]-This indicates a part supplied as semi-finished. It requires additional work before installation.	-1	SN: UP

Komatsu SAA6D125E-5ER S/N 579001-UP (For WA480-6R) parts catalog PDF

PISTON AND CONNECTING ROD, (#579001-) (A2350-001001) in SAA6D125E-5ER S/N 579001-UP (For WA480-6R). Diagram image and parts list.
