SAA6D125E-5ER S/N 579001-UP (For WA480-6R)

7 6 2 26 25 23 24 5 8 9 10 11 28 29 36 35 20 22 34 21 13 30 31 28 27 19 18 37 15 14 16 17 13 1 12 33 32 4 2 3

#	Part Number	Partname	Quantity	Options
\|$0	6251-71-1121	Pump Assembly, Fuel Injection	1	SN: 579001-UP
\|$1	ND094100-0460	Body Assembly	1	SN: 579001-UP \| SCC: C2
1	ND094110-0210	Housing Assembly	1	SN: 579001-UP \| SCC: C2
2	ND094040-0370	Element Assembly	2	SN: 579001-UP \| SCC: C2
3	ND094086-0090	O-ring	2	SN: 579001-UP \| SCC: C2
4	ND094140-0040	Valve Assembly	2	SN: 579001-UP \| SCC: C2
5	ND094086-0100	O-ring	4	SN: 579001-UP \| SCC: C2
6	ND949013-5880	Washer	4	SN: 579001-UP \| SCC: C2
7	ND92156-08081	Nut	4	SN: 579001-UP \| SCC: C2
8	ND094162-0040	Seat	2	SN: 579001-UP \| SCC: C2
9	ND094164-0010	Spring	2	SN: 579001-UP \| SCC: C2
10	ND094165-0021	Seat	2	SN: 579001-UP \| SCC: C2
11	ND094170-0100	Tappet Assembly	2	SN: 579001-UP \| SCC: C2
12	ND094191-0161	Camshaft	1	SN: 579001-UP \| SCC: C2
13	ND949101-0230	Bearing, Roller	2	SN: 579001-UP \| SCC: C2
14	ND094104-0100	Cover	1	SN: 579001-UP \| SCC: C2
15	ND949150-3030	Seal, Oil	1	SN: 579001-UP \| SCC: C2
16	ND094086-0120	O-ring	1	SN: 579001-UP \| SCC: C2
17	ND094095-0100	Shim, T=0.05mm	0	SN: 579001-UP \| SCC: C2
\|$19	ND094095-0130	Shim, T=0.10mm	0	SN: 579001-UP \| SCC: C2
\|$20	ND094095-0140	Shim, T=0.20mm	0	SN: 579001-UP \| SCC: C2
\|$21	ND094095-0150	Shim, T=0.30mm	0	SN: 579001-UP \| SCC: C2
\|$22	ND094095-0160	Shim, T=0.50mm	0	SN: 579001-UP \| SCC: C2
18	ND094092-0010	Washer	4	SN: 579001-UP \| SCC: C2
19	ND949044-3320	Bolt	4	SN: 579001-UP \| SCC: C2
20	ND094086-0110	O-ring	1	SN: 579001-UP \| SCC: C2
21	ND094086-0130	O-ring	1	SN: 579001-UP \| SCC: C2
22	ND094093-0050	Shim, T=0.40mm	0	SN: 579001-UP \| SCC: C2
\|$28	ND094093-0060	Shim, T=0.60mm	0	SN: 579001-UP \| SCC: C2
\|$29	ND094093-0070	Shim, T=0.80mm	0	SN: 579001-UP \| SCC: C2
\|$30	ND094093-0080	Shim, T=1.00mm	0	SN: 579001-UP \| SCC: C2
23	ND949979-1300	Sensor Assembly	1	SN: 579001-UP \| SCC: C2
\|$32		O-ring	1	SN: 579001-UP \| SCC: C1
24	ND094096-0050	Shim, T=0.15mm	0	SN: 579001-UP \| SCC: C2
\|$34	ND094096-0060	Shim, T=0.20mm	0	SN: 579001-UP \| SCC: C2
\|$35	ND094096-0070	Shim, T=0.25mm	0	SN: 579001-UP \| SCC: C2
\|$36	ND094096-0080	Shim, T=0.40mm	0	SN: 579001-UP \| SCC: C2
25	ND90200-06081	Washer	1	SN: 579001-UP \| SCC: C2
26	ND90107-06161	Bolt	1	SN: 579001-UP \| SCC: C2
27	ND090310-0500	Valve Assembly	1	SN: 579001-UP
28	ND090222-0070	Washer	5	SN: 579001-UP
29	ND949180-0310	Screw	1	SN: 579001-UP
30	ND090222-0120	Washer	2	SN: 579001-UP
31	ND949180-0060	Screw	1	SN: 579001-UP
32	ND949018-0350	Washer	1	SN: 579001-UP \| SCC: C2
33	ND090317-0480	Plug	1	SN: 579001-UP
34	ND090207-0100	Ring	1	SN: 579001-UP
35	ND090244-0010	Screw	1	SN: 579001-UP
36	ND949010-3020	Washer	1	SN: 579001-UP
37	ND094086-0210	O-ring	1	SN: 579001-UP
\|$50		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
\|$51		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu SAA6D125E-5ER S/N 579001-UP (For WA480-6R) parts catalog PDF

FUEL SUPPLY PUMP, INNER PARTS, PUMP(#579001-) (A4010-003001) in SAA6D125E-5ER S/N 579001-UP (For WA480-6R). Diagram image and parts list.
